Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
 +13

Lenovo ThinkPad P P15 Gen 1 20ST003XUS
Price, score and specs

Video, design & 3D 5.4
Power and specifications 49
18
Processor
27
Graphics
79
Screen
79
RAM
80
Storage
Prices
In 1 store
Prices

Local stores

See price

Main specs

Processor

Intel Core i7-10750H 2,6GHz

Screen 15.6" 1920x1080 IPS 500 nits 72% NTSC
Hard drive 512GB SSD M.2
RAM 16GB DDR4-SDRAM
Operating system Windows 10 Pro
Graphics card

NVIDIA Quadro T1000 4GB GDDR6

Other Keyboard English.

Other configurations of this model

Score Power Price ▲ Processor Graphics card Screen RAM Hard drive
5.4  49 Current Intel Core i7-10750HNVIDIA Quadro T1000 4GBIPS16GB512GB
6.4  53 $1850 Intel Core i7-10750HNVIDIA Quadro T1000 4GBWVA32GB1TB
7.4  58 $2499 Intel Core i9-10885HNVIDIA Quadro RTX 4000 Max-Q 8GBIPS32GB1TB
6.1  52 $2499.99 Intel Core i7-10850HNVIDIA Quadro T2000 4GBIPS32GB1TB
5.6  52 $3399 Intel Core i9-10885HNVIDIA Quadro T2000 4GBIPS32GB512GB

Full specifications of Lenovo ThinkPad P P15 Gen 1 20ST003XUS

Reference / Part Number 20ST003XUS
Release date July 2020, 6 years ago

Design

Product type Mobile workstation
Product color Black
Form factor Clamshell

Image gallery

  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs
  • Lenovo ThinkPad P P15 Gen 1 20ST003XUS Price, score and specs

Screen

Display diagonal 15.6 " (39,6 cm)
Display resolution 1920 x 1080 pixels
Touchscreen No
HD type Full HD
Panel type IPS
LED backlight Yes
Native aspect ratio 16:9
Anti-glare screen Yes
Display brightness 500 cd/m²
RGB color space NTSC
Color gamut 72 %
Contrast ratio (typical) 1200:1
High Dynamic Range (HDR) supported Yes
High Dynamic Range (HDR) technology Dolby Vision

Processor

Processor family Intel® Core™ i7
Processor manufacturer Intel
Processor model i7-10750H
Processor frequency 2,6 GHz
Generación del procesador Intel Core i7-10xxx
Processor cores 6
Processor threads 12
Processor boost frequency 5 GHz
System bus rate 8 GT/s
Processor cache 12 MB
Processor cache type Smart Cache
Processor socket BGA 1440
Processor lithography 14 nm
Processor operating modes 64-bit
Processor codename Comet Lake
Thermal Design Power (TDP) 45 W
Configurable TDP-down 35 W
Tjunction 100 °C
Maximum number of PCI Express lanes 16
PCI Express slots version 3.0
PCI Express configurations 1x16,2x8,1x8+2x4

Memory

Internal memory 16 GB
Maximum internal memory 128 GB
Internal memory type DDR4-SDRAM
Memory clock speed 2933 MHz
Memory form factor SO-DIMM
Memory layout (slots x size) 2 x 8 GB
Memory slots 4x SO-DIMM
Memory channels Dual-channel
ECC No

Storage

Total storage capacity 512 GB
Storage media SSD
Optical drive type No
Total SSDs capacity 512 GB
Number of SSDs installed 1
SSD capacity 512 GB
SSD interface PCI Express 3.0
NVMe Yes
SSD form factor M.2
Card reader integrated Yes
Compatible memory cards SD

Graphics

On-board graphics card Yes
Discrete graphics card Yes
Discrete graphics card model NVIDIA Quadro T1000
On-board graphics card model Intel® UHD Graphics
Discrete graphics card memory 4 GB
Discrete graphics memory type GDDR6
Fabricante de GPU (unidad de procesamiento gráfico) integrada Intel
On-board graphics card base frequency 350 MHz
On-board graphics card dynamic frequency (max) 1150 MHz
On-board graphics card DirectX version 12.0
On-board graphics card OpenGL version 4.5
On-board graphics card ID 0x9BC4

Audio

Audio chip Realtek ALC3286
Audio system Dolby Atmos
Number of built-in speakers 2
Speaker power 2 W
Built-in microphone Yes
Number of microphones 2

Camera

Front camera Yes
Front camera resolution 1280 x 720 pixels
Front camera HD type HD
Infrared (IR) camera Yes
Privacy camera Yes
Privacy type Privacy shutter

Network

Mobile network connection No
Top Wi-Fi standard Wi-Fi 6 (802.11ax)
Wi-Fi Yes
Wi-Fi standards Wi-Fi 6 (802.11ax)
Wi-Fi data rate (max) 2400 Mbit/s
Antenna type 2x2
WLAN controller model Intel Wi-Fi 6 AX201
WLAN controller manufacturer Intel
Ethernet LAN Yes
Ethernet LAN data rates 100,1000 Mbit/s
Bluetooth Yes
Bluetooth version 5.1
WWAN Installed

Ports & interfaces

USB 2.0 ports quantity 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
HDMI ports quantity 1
Ethernet LAN (RJ-45) ports 1
HDMI version 2.0
Thunderbolt 3 ports quantity 2
Combo headphone/mic port Yes
USB Type-C DisplayPort Alternate Mode Yes
USB Sleep-and-Charge Yes
USB Sleep-and-Charge ports 1

Performance

Motherboard chipset Intel WM490

Keyboard

Numeric keypad Yes
Pointing device ThinkPad UltraNav
Keyboard backlit Yes
Spill-resistant keyboard Yes
Keyboard layout QWERTY
Keyboard language English

Software

Operating system installed Windows 10 Pro
Operating system architecture 64-bit
Operating system language English

Processor special features

Intel® Identity Protection Technology (Intel® IPT) Yes
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Enhanced Intel SpeedStep Technology Yes
Intel® Quick Sync Video Technology Yes
Intel Flex Memory Access Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Intel Trusted Execution Technology No
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel Stable Image Platform Program (SIPP) No
Intel® OS Guard Yes
Intel Software Guard Extensions (Intel SGX) Yes
Intel 64 Yes
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Processor package size 42 x 28 mm
Supported instruction sets SSE4.1,SSE4.2,AVX 2.0
CPU configuration (max) 1
Embedded options available No
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Virtualization Technology (VT-x) Yes
Processor ARK ID 201837

Battery

Battery capacity 94 Wh
Battery technology Lithium Polymer (LiPo)
Battery life (max) 16,4 h

Power

AC adapter power 170 W
DC-in jack Yes
USB Power Delivery Yes

Security

Cable lock slot Yes
Cable lock slot type Kensington
Fingerprint reader Yes
Smart card reader No
Windows Hello Yes
Trusted Platform Module (TPM) Yes
Trusted Platform Module (TPM) version 2.0
Password protection Yes
Password protection type HDD,Power on,Supervisor

Operational conditions

Operating temperature (T-T) 5 - 35 °C
Storage temperature (T-T) 5 - 43 °C
Operating relative humidity (H-H) 8 - 95 %
Storage relative humidity (H-H) 5 - 95 %
Maximum shipping altitude 3048 m

Aprobaciones reguladoras

Certificados de conformidad RoHS
Certification MIL-STD-810G

Sustainability

Sustainability certificates EPEAT Gold,ENERGY STAR

Weight & dimensions

Weight 6 lbs (2,74 kg)
Width 14.8 " (375,4 mm)
Depth 9.9 " (252,3 mm)
Height (front) 1 " (2,45 cm)
Height (rear) 1.2 " (3,15 cm)

Alternatives with equal or higher power at a similar or lower price

From Lenovo

From other brands


Frequently asked questions

How good is the Lenovo ThinkPad P P15 Gen 1 20ST003XUS?

It is a Video, design & 3D laptop that falls short of the power that use calls for today: 49 out of 100 against the most powerful in the catalog. For light tasks it can do.

Is the Lenovo ThinkPad P P15 Gen 1 20ST003XUS worth its price?

Barely: today it starts at $1730 and its 5.4 in the Kelaptop Value-for-Money Score says it meets the minimum you should expect for that money; looking at alternatives you can find more for the same.

How much does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS cost?

Today it starts at $1730 in 1 store. Prices are checked daily.

Is the Lenovo ThinkPad P P15 Gen 1 20ST003XUS good for gaming?

You can game on it, though this laptop was built for video, design and 3D work: it carries the NVIDIA Quadro T1000. Its card's page shows how it performs in games.

How long does the battery of the Lenovo ThinkPad P P15 Gen 1 20ST003XUS last?

The manufacturer declares up to 16,4 h of battery life. Real duration depends on brightness, workload and battery health.

What is the screen of the Lenovo ThinkPad P P15 Gen 1 20ST003XUS like?

It carries a 15.6" 1920x1080 IPS 500 nits 72% NTSC display.

Which processor and graphics card does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS have?

It runs on the Intel Core i7-10750H processor with the NVIDIA Quadro T1000 graphics. Their pages carry their benchmarks, ranking position and alternatives.

Can the RAM of the Lenovo ThinkPad P P15 Gen 1 20ST003XUS be upgraded?

Yes: it has 4 memory slots and takes up to 128 GB according to the manufacturer (it ships with 16GB).

Which operating system does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS come with?

It comes with Windows 10 Pro preinstalled.

Which ports does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS have?

According to its spec sheet: 2 × Thunderbolt 3, 1 × USB-C, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).

Does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS have a backlit keyboard?

Yes, according to its spec sheet the keyboard is backlit.

Does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS have a touch screen?

No, according to its spec sheet the screen is not a touch screen.

How much does the Lenovo ThinkPad P P15 Gen 1 20ST003XUS weigh?

It weighs 2,74 kg: one of the heavy ones, more of a desk machine than a daily commuter.

When was the Lenovo ThinkPad P P15 Gen 1 20ST003XUS released?

Its release date is July 2020, 6 years ago.
