DELL XPS 15 9520 62DV3
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 15.6" 3840x2400 WLED 60Hz 500 nits 100% Adobe RGB |
| Hard drive | 1TB SSD M.2 |
| RAM | 32GB DDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | NVIDIA GeForce RTX 3050 Ti 4GB GDDR6 |
| Other | Keyboard German. |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of DELL XPS 15 9520 62DV3
| Reference / Part Number | 62DV3 |
|---|---|
| Release date | July 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Platinum,Silver |
| Form factor | Clamshell |
| Housing material | Aluminium |
| Market positioning | Home |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 3840 x 2400 pixels |
| Touchscreen | Yes |
| HD type | UHD+ |
| Panel type | WLED |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display brightness | 500 cd/m² |
| Pixel pitch | 0,0900 x 0,0900 mm |
| Pixel density | 290 ppi |
| RGB colour space | Adobe RGB |
| Colour gamut | 100 % |
| Display response rise/fall | 35 ms |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 1600:1 |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-12700H |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor cores | 14 |
| Processor boost frequency | 4,7 GHz |
| Processor cache | 24 MB |
| Configurable TDP-down | 35 W |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | NVMe,PCI Express |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD,SDHC,SDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 3050 Ti |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete GPU manufacturer | Intel |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
| Maximum on-board graphics card resolution | 7680 x 4320 pixels |
| Maximum discrete graphics card resolution | 7680 x 4320 pixels |
Audio
| Audio chip | Realtek ALC3281 |
|---|---|
| Number of built-in speakers | 4 |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,9 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Bluetooth | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 0 |
| VGA (D-Sub) ports quantity | 0 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard layout | QWERTZ |
| Keyboard language | German |
Software
| Operating system installed | Windows 11 Pro |
|---|---|
| Operating system architecture | 64-bit |
| Operating system language | DEU,DUT,ENG,FRE,ITA |
| Trial software | McAfee® Business Protection 30-day Trial,No Microsoft Office License Included 30 day Trial Offer Only |
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 86 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Battery recharge time | 3 h |
| Fast charging | Yes |
| Battery charge indicator | Yes |
| Battery weight | 340 g |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 130 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Power Delivery (USB PD) | Yes |
| USB charging voltage | 20 V |
| USB charging current | 6.5 A |
Security
| Cable lock slot | Yes |
|---|---|
| Password protection | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 140 G |
| Non-operating shock | 160 G |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Weight & dimensions
| Weight | 1,96 kg |
|---|---|
| Width | 344,4 mm |
| Depth | 230,1 mm |
| Height (front) | 1,85 cm |
| Height (rear) | 1,17 cm |
Packaging content
| Cables included | AC |
|---|
Frequently asked questions
Is the DELL XPS 15 9520 62DV3 good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 3050 Ti. Its card's page shows what level it handles current games at.
What is the screen of the DELL XPS 15 9520 62DV3 like?
It carries a 15.6" 3840x2400 WLED 60Hz 500 nits 100% Adobe RGB display.
Which processor and graphics card does the DELL XPS 15 9520 62DV3 have?
It runs on the Intel Core i7-12700H processor with the NVIDIA GeForce RTX 3050 Ti graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the DELL XPS 15 9520 62DV3 be upgraded?
Yes: it has 2 memory slots and takes up to 64 GB according to the manufacturer (it ships with 32GB).
Which operating system does the DELL XPS 15 9520 62DV3 come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the DELL XPS 15 9520 62DV3 have?
According to its spec sheet: 2 × Thunderbolt 4, 1 × USB-C, card reader, headphone jack (3.5 mm).
Does the DELL XPS 15 9520 62DV3 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the DELL XPS 15 9520 62DV3 have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the DELL XPS 15 9520 62DV3 made of?
Its housing is made of Aluminium.
How much does the DELL XPS 15 9520 62DV3 weigh?
It weighs 1,96 kg, a normal weight for its size: easy enough to move around.
When was the DELL XPS 15 9520 62DV3 released?
Its release date is July 2022, 4 years ago.
