DELL G15 5520 D560738WIN9B
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 15.6" 2560x1440 WVA 240Hz 400 nits 99% DCI-P3 |
| Hard drive | 1TB SSD M.2 |
| RAM | 16GB DDR5-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | NVIDIA GeForce RTX 3060 6GB GDDR6 |
| Other | Keyboard US English. |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of DELL G15 5520 D560738WIN9B
| Reference / Part Number | D560738WIN9B |
|---|---|
| Release date | July 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Gray |
| Form factor | Clamshell |
| Color name | Obsidian Black Special Edition |
| Market positioning | Gaming |
Image gallery
Screen
| Display diagonal | 15.6 " (39,6 cm) |
|---|---|
| Display resolution | 2560 x 1440 pixels |
| Touchscreen | No |
| HD type | Quad HD |
| Panel type | WVA |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| Display brightness | 400 cd/m² |
| Pixel pitch | 0,179 x 0,179 mm |
| Pixel density | 141 ppi |
| RGB color space | DCI-P3 |
| Color gamut | 99 % |
| Display response rise/fall | 10 ms |
| Maximum refresh rate | 240 Hz |
| Contrast ratio (typical) | 800:1 |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-12700H |
| Generación del procesador | Intel Core i7-12xxx |
| Processor cores | 14 |
| Processor boost frequency | 4,7 GHz |
| Processor cache | 24 MB |
| Configurable TDP-down | 35 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | NVMe,PCI Express |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 3060 |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card memory | 6 GB |
| Discrete graphics memory type | GDDR6 |
Audio
| Audio chip | Realtek ALC3254 |
|---|---|
| Audio system | Dolby Audio |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,92 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| WLAN controller model | Killer Wireless-AX 1650i |
| WLAN controller manufacturer | Killer |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.1 |
| Número de puertos Thunderbolt 4 | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard language | US English |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 86 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 13,2 V |
| Battery recharge time | 4 h |
| Battery weight | 12 oz (340 g) |
Power
| AC adapter power | 240 W |
|---|---|
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 12,31 A |
| AC adapter output voltage | 19.5 V |
| DC-in jack | Yes |
Security
| Password protection | Yes |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
Weight & dimensions
| Weight | 6.2 lbs (2,81 kg) |
|---|---|
| Width | 14.1 " (357,3 mm) |
| Depth | 10.7 " (272,1 mm) |
| Height (front) | 0.8 " (2,13 cm) |
| Height (rear) | 1 " (2,53 cm) |
Packaging content
| Cables included | AC |
|---|
Frequently asked questions
Is the DELL G15 5520 D560738WIN9B good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 3060. Its card's page shows what level it handles current games at.
What is the screen of the DELL G15 5520 D560738WIN9B like?
It carries a 15.6" 2560x1440 WVA 240Hz 400 nits 99% DCI-P3 display.
Which processor and graphics card does the DELL G15 5520 D560738WIN9B have?
It runs on the Intel Core i7-12700H processor with the NVIDIA GeForce RTX 3060 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the DELL G15 5520 D560738WIN9B be upgraded?
Yes: it has 2 memory slots and takes up to 32 GB according to the manufacturer (it ships with 16GB).
Which operating system does the DELL G15 5520 D560738WIN9B come with?
It comes with Windows 11 Home preinstalled.
Which ports does the DELL G15 5520 D560738WIN9B have?
According to its spec sheet: 1 × Thunderbolt 4, 3 × USB-A, 1 × HDMI, Ethernet (RJ-45), headphone jack (3.5 mm).
Does the DELL G15 5520 D560738WIN9B have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the DELL G15 5520 D560738WIN9B have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the DELL G15 5520 D560738WIN9B weigh?
It weighs 2,81 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the DELL G15 5520 D560738WIN9B released?
Its release date is July 2022, 4 years ago.
