ASUS Zenbook Pro UX535LI-H2172R
Specs
Prices
Main specs
| Processor | Intel Core i7-10870H 2,2GHz |
|---|---|
| Screen | 15.6" 3840x2160 OLED 60Hz 400 nits |
| Hard drive | 1TB SSD M.2 |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 10 Pro |
| Graphics card | NVIDIA GeForce GTX 1650 Ti 4GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From ASUS
Full specifications of ASUS Zenbook Pro UX535LI-H2172R
| Reference / Part Number | 90NB0RW1-M05310 |
|---|---|
| Release date | February 2021, 5 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Gray |
| Form factor | Clamshell |
| Color name | Pine Grey |
Image gallery
Screen
| Display diagonal | 15.6 " (39,6 cm) |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Panel type | OLED |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display brightness | 400 cd/m² |
| Maximum refresh rate | 60 Hz |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-10870H |
| Processor frequency | 2,2 GHz |
| Generación del procesador | Intel Core i7-10xxx |
| Processor cores | 8 |
| Processor boost frequency | 5 GHz |
| Processor cache | 15 MB |
| Configurable TDP-down | 35 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2933 MHz |
| Memory form factor | On-board |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | NVMe,PCI Express 3.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MMC,SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA® GeForce® GTX 1650 Ti |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
Audio
| Audio system | SonicMaster |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Combo headphone/mic port | Yes |
Performance
| Repairability index | 6.1 |
|---|
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | ScreenPad |
| Keyboard backlit | Yes |
| Full-size keyboard | Yes |
Software
| Operating system installed | Windows 10 Pro |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
|---|---|
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery technology | Lithium-Ion (Li-Ion) |
|---|
Power
| AC adapter power | 150 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 20 V |
| DC-in jack | Yes |
Security
| Windows Hello | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Weight & dimensions
| Weight | 4 lbs (1,8 kg) |
|---|---|
| Width | 13.9 " (354 mm) |
| Depth | 9.2 " (233 mm) |
| Height (front) | 0.7 " (1,78 cm) |
| Height (rear) | 0.7 " (1,8 cm) |
Frequently asked questions
Is the ASUS Zenbook Pro UX535LI-H2172R good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce GTX 1650 Ti. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Zenbook Pro UX535LI-H2172R like?
It carries a 15.6" 3840x2160 OLED 60Hz 400 nits display.
Which processor and graphics card does the ASUS Zenbook Pro UX535LI-H2172R have?
It runs on the Intel Core i7-10870H processor with the NVIDIA GeForce GTX 1650 Ti graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS Zenbook Pro UX535LI-H2172R come with?
It comes with Windows 10 Pro preinstalled.
Which ports does the ASUS Zenbook Pro UX535LI-H2172R have?
According to its spec sheet: 1 × Thunderbolt 3, 1 × USB-C, 1 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the ASUS Zenbook Pro UX535LI-H2172R have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
How much does the ASUS Zenbook Pro UX535LI-H2172R weigh?
It weighs 1,8 kg, a normal weight for its size: easy enough to move around.
When was the ASUS Zenbook Pro UX535LI-H2172R released?
Its release date is February 2021, 5 years ago.
