ASUS ProArt StudioBook 16 Studiobook
Specs
Prices
Main specs
| Processor | AMD Ryzen 9 5900HX 3,3GHz |
|---|---|
| Screen | 16" 2560x1600 IPS 120Hz 500 nits 100% DCI-P3 |
| Hard drive | 1TB SSD |
| RAM | 64GB DDR4-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | NVIDIA GeForce RTX 3070 8GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS ProArt StudioBook 16 Studiobook
| Reference / Part Number | H5600QR-XB99 |
|---|---|
| Release date | October 2021, 5 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Black |
| Form factor | Clamshell |
| Market positioning | Business |
| Original brand name | ASUS |
Image gallery
Screen
| Display diagonal | 16 " (40,6 cm) |
|---|---|
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| HD type | WQXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Display surface | Matt |
| Anti-glare screen | Yes |
| Display brightness | 500 cd/m² |
| RGB color space | DCI-P3 |
| Color gamut | 100 % |
| Maximum refresh rate | 120 Hz |
Processor
| Processor family | AMD Ryzen™ 9 |
|---|---|
| Processor manufacturer | AMD |
| Processor model | 5900HX |
| Processor frequency | 3,3 GHz |
| Generación del procesador | AMD Ryzen 5000 Series |
| Processor cores | 8 |
| Processor boost frequency | 4,6 GHz |
| Processor cache | 16 MB |
Memory
| Internal memory | 64 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory form factor | SO-DIMM |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 1 TB |
| SSD interface | M.2,NVMe,PCI Express 3.0 |
| NVMe | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 3070 |
| On-board graphics card model | AMD Radeon RX Vega 7 |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card family | AMD Radeon Vega Graphics |
| NVIDIA Max-Q | Yes |
Audio
| Audio system | SonicMaster |
|---|---|
| Number of built-in speakers | 1 |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTY |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Pro |
|---|
Battery
| Battery capacity | 90 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Power
| AC adapter power | 240 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 12 A |
| AC adapter output voltage | 20 V |
| DC-in jack | Yes |
| USB Power Delivery | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Windows Hello | Yes |
| Password protection | Yes |
| Password protection type | BIOS,User |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 5.3 lbs (2,4 kg) |
|---|---|
| Width | 14.3 " (362 mm) |
| Depth | 10.4 " (264 mm) |
| Height | 0.8 " (19,9 mm) |
Frequently asked questions
Is the ASUS ProArt StudioBook 16 Studiobook good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 3070. Its card's page shows what level it handles current games at.
What is the screen of the ASUS ProArt StudioBook 16 Studiobook like?
It carries a 16" 2560x1600 IPS 120Hz 500 nits 100% DCI-P3 display.
Which processor and graphics card does the ASUS ProArt StudioBook 16 Studiobook have?
It runs on the AMD Ryzen 9 5900HX processor with the NVIDIA GeForce RTX 3070 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the ASUS ProArt StudioBook 16 Studiobook be upgraded?
It has 2 memory slots, but it already ships with the maximum it takes (64 GB).
Which operating system does the ASUS ProArt StudioBook 16 Studiobook come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the ASUS ProArt StudioBook 16 Studiobook have?
According to its spec sheet: 2 × USB-C, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the ASUS ProArt StudioBook 16 Studiobook have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the ASUS ProArt StudioBook 16 Studiobook have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the ASUS ProArt StudioBook 16 Studiobook weigh?
It weighs 2,4 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the ASUS ProArt StudioBook 16 Studiobook released?
Its release date is October 2021, 5 years ago.
