Alienware m15 R3 AWR3-0938
Specs
Prices
Main specs
| Processor | Intel Core i7-10750H 2,6GHz |
|---|---|
| Screen | 15.6" 3840x2160 OLED 60Hz 400 nits |
| Hard drive | 1TB SSD M.2 |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card | NVIDIA GeForce RTX 2070 Super 8GB GDDR6 |
| Other | Keyboard French. |
Alternatives with equal or higher power at a similar or lower price
Full specifications of Alienware m15 R3 AWR3-0938
| Reference / Part Number | AWR3-0938 |
|---|---|
| Release date | July 2020, 6 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Silver,White |
| Form factor | Clamshell |
| Color name | Lunar Light |
Image gallery
Screen
| Display diagonal | 15.6 " (39,6 cm) |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | OLED |
| Display brightness | 400 cd/m² |
| Pixel pitch | 0,0900 x 0,0900 mm |
| Pixel density | 282 ppi |
| Display response rise/fall | 1 ms |
| Maximum refresh rate | 60 Hz |
| Tecnología de seguimiento ocular de Tobii | Yes |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-10750H |
| Processor frequency | 2,6 GHz |
| Generación del procesador | Intel Core i7-10xxx |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor boost frequency | 5 GHz |
| System bus rate | 8 GT/s |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1440 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Comet Lake |
| Thermal Design Power (TDP) | 45 W |
| Configurable TDP-down | 35 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16,2x8,1x8+2x4 |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Memory form factor | On-board |
| Memory layout (slots x size) | 1 x 16 GB |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 2070 Super |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x9BC4 |
Audio
| Audio chip | Realtek ALC3281-CG |
|---|---|
| Number of built-in speakers | 4 |
| Speaker power | 4 W |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,92 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller model | Killer Wireless-AX 1650 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.0 |
| Mini DisplayPorts quantity | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Combo headphone/mic port | Yes |
| PowerShare | Yes |
| Number of USB ports with PowerShare support | 1 |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard language | French |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|---|
| Operating system architecture | 64-bit |
| Bundled software | Financial Tracker & Retail Information |
Processor special features
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
|---|---|
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 42 x 28 mm |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 201837 |
Battery
| Battery capacity | 86 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Battery weight | 12 oz (340 g) |
Power
| AC adapter power | 240 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 12,31 A |
| AC adapter output voltage | 19.5 V |
| DC-in jack | Yes |
Security
| Password protection | Yes |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 10 - 90 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 3.9 oz (110 G) |
| Non-operating shock | 5.6 oz (160 G) |
| Operating vibration | 0 oz (0,66 G) |
| Non-operating vibration | 0 oz (1,3 G) |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 5.5 lbs (2,5 kg) |
|---|---|
| Width | 14.2 " (360,3 mm) |
| Depth | 10.9 " (276,2 mm) |
| Height (front) | 0.7 " (1,83 cm) |
| Height (rear) | 0.8 " (1,97 cm) |
Packaging data
| Package width | 16.4 " (415,8 mm) |
|---|---|
| Package depth | 18 " (456,1 mm) |
| Package height | 4.6 " (117,4 mm) |
| Package weight | 10.3 lbs (4,66 kg) |
| Package material | Corrugated cardboard,Polypropylene (PP) |
Recycling data
| Paper molded pulp content per package | 0 oz (0 g) |
|---|---|
| Bamboo molded pulp content per package | 0 oz (0 g) |
| Wheat straw molded pulp content per package | 0 oz (0 g) |
| Grey board content per package | 0 oz (0 g) |
| Corrugated cardboard content per package | 3.1 lbs (1,39 kg) |
| Corrugated cardboard content per shipping (inner) case | 34.3 oz (971 g) |
| Corrugated cardboard content per box for accessories | 7.6 oz (215 g) |
| Corrugated cardboard content per sleeve for accessories | 7 oz (199 g) |
| Polyethylene terephthalate (PET) content per package | 0 oz (0 g) |
| High-density polyethylene (HDPE) content per package | 0 oz (0 g) |
| Low-density polyethylene (LDPE) content per package | 0 oz (0 g) |
| Polypropylene (PP) content per package | 0.7 oz (19 g) |
| Polystyrene (PS) content per package | 0 oz (0 g) |
| Other materials content per package | 4.2 oz (120 g) |
Logistics data
| Quantity per intermodal container (20ft) | 800 pc(s) |
|---|---|
| Quantity per intermodal container (40ft) | 1680 pc(s) |
| Pallet width | 39.4 " (100 cm) |
| Pallet length | 47.2 " (120 cm) |
| Pallet weight | 428.1 lbs (194,2 kg) |
| Pallet volume weight | 165.3 lbs (75 kg) |
| Number of layers per pallet | 2 pc(s) |
| Quantity per pallet layer | 20 pc(s) |
| Quantity per pallet | 40 pc(s) |
| Maximum number of stacking cartons | 4 pc(s) |
Other features
| EPEAT rating | 90,88 % |
|---|
Frequently asked questions
Is the Alienware m15 R3 AWR3-0938 good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 2070 Super. Its card's page shows what level it handles current games at.
What is the screen of the Alienware m15 R3 AWR3-0938 like?
It carries a 15.6" 3840x2160 OLED 60Hz 400 nits display.
Which processor and graphics card does the Alienware m15 R3 AWR3-0938 have?
It runs on the Intel Core i7-10750H processor with the NVIDIA GeForce RTX 2070 Super graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Alienware m15 R3 AWR3-0938 come with?
It comes with Windows 10 Home preinstalled.
Which ports does the Alienware m15 R3 AWR3-0938 have?
According to its spec sheet: 1 × Thunderbolt 3, 3 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the Alienware m15 R3 AWR3-0938 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Alienware m15 R3 AWR3-0938 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the Alienware m15 R3 AWR3-0938 weigh?
It weighs 2,5 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the Alienware m15 R3 AWR3-0938 released?
Its release date is July 2020, 6 years ago.
