MSI Summit E16 AI Studio A1VFTG-007FR
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 16" 2560x1600 165Hz 100% DCI-P3 |
| Hard drive | 1TB SSD M.2 |
| RAM | 32GB LPDDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of MSI Summit E16 AI Studio A1VFTG-007FR
| Reference / Part Number | SUMMIT E16 AI STUDIO A1VFTG-007FR |
|---|---|
| Also sold as | SUMMIT E16 AI STUDIO A1VETG-008FR |
| Release date | December 2023, 2 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product color | Black |
| Form factor | Convertible (Folder) |
Image gallery
Screen
| Display diagonal | 16 " (40,6 cm) |
|---|---|
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | Yes |
| HD type | Quad HD+ |
| Native aspect ratio | 16:10 |
| RGB color space | DCI-P3 |
| Color gamut | 100 % |
| Maximum refresh rate | 165 Hz |
Processor
| Processor family | Intel Core Ultra 7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | 155H |
| Processor cores | 16 |
| Processor boost frequency | 4,8 GHz |
| Núcleos de rendimiento | 6 |
| Núcleos de eficiencia | 8 |
| Frecuencia turbo máxima del núcleo de rendimiento | 1.4 |
| Frecuencia turbo máxima del núcleo de eficiencia | 3.8 |
| Frecuencia base de núcleo de rendimiento | 4.8 |
| Frecuencia base de núcleo eficiente | 0.9 |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Potencia base del procesador | 28 |
| Potencia turbo máxima | 115 |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory clock speed | 6400 MHz |
| Memory form factor | On-board |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Arc Graphics |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
| On-board graphics card family | Intel Arc Graphics |
Audio
| Audio system | Nahimic 3D |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1920 x 1080 pixels |
| Front camera HD type | Full HD |
| Video capturing speed | 30 fps |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Número de puertos Thunderbolt 4 | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Pro |
|---|
Battery
| Battery capacity | 82 Wh |
|---|---|
| Number of battery cells | 4 |
Power
| AC adapter power | 140 W |
|---|
Weight & dimensions
| Weight | 4.6 lbs (2,1 kg) |
|---|---|
| Width | 14.1 " (358 mm) |
| Depth | 10.2 " (258,6 mm) |
| Height (front) | 0.7 " (1,69 cm) |
| Height (rear) | 0.7 " (1,74 cm) |
Frequently asked questions
Is the MSI Summit E16 AI Studio A1VFTG-007FR good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel Arc Graphics. Its card's page shows what level it handles current games at.
What is the screen of the MSI Summit E16 AI Studio A1VFTG-007FR like?
It carries a 16" 2560x1600 165Hz 100% DCI-P3 display.
Which processor and graphics card does the MSI Summit E16 AI Studio A1VFTG-007FR have?
It runs on the Intel Core Ultra 7 155H processor with the Intel Arc Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the MSI Summit E16 AI Studio A1VFTG-007FR come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the MSI Summit E16 AI Studio A1VFTG-007FR have?
According to its spec sheet: 1 × Thunderbolt 4, 1 × USB-C, 1 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the MSI Summit E16 AI Studio A1VFTG-007FR have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the MSI Summit E16 AI Studio A1VFTG-007FR have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
How much does the MSI Summit E16 AI Studio A1VFTG-007FR weigh?
It weighs 2,1 kg, a normal weight for its size: easy enough to move around.
When was the MSI Summit E16 AI Studio A1VFTG-007FR released?
Its release date is December 2023, 2 years ago.
