MSI CreatorPro X17 X17HX A13VM-259FR
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 17.3" 3840x2160 Mini LED 144Hz 100% DCI-P3 |
| Hard drive | 4TB SSD |
| RAM | 128GB DDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | NVIDIA RTX 5000 Ada 16GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of MSI CreatorPro X17 X17HX A13VM-259FR
| Reference / Part Number | CREATORPRO X17HX A13VM-259FR |
|---|---|
| Release date | September 2023, 3 years ago |
Design
| Product type | Mobile workstation |
|---|---|
| Product colour | Black |
| Form factor | Clamshell |
| Colour name | Core Black |
| Original brand name | MSI |
Image gallery
Screen
| Display diagonal | 43,9 cm |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | Mini LED |
| Native aspect ratio | 16:9 |
| Display diagonal (metric) | 43,9 cm |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Maximum refresh rate | 144 Hz |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range (HDR) 1000 |
Processor
| Processor family | Intel® Core™ i9 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i9-13980HX |
| Processor generation | 13th gen Intel® Core™ i9 |
| Processor cores | 24 |
| Processor boost frequency | 5,6 GHz |
| Performance cores | 8 |
| Efficient cores | 16 |
| Performance-core Max Turbo Frequency | 5,6 GHz |
| Efficient-core Max Turbo Frequency | 4 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
Memory
| Internal memory | 128 GB |
|---|---|
| Maximum internal memory | 128 GB |
| Internal memory type | DDR5-SDRAM |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 4 x 32 GB |
| Memory slots | 4x SO-DIMM |
Storage
| Total storage capacity | 4 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 4 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 2 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA RTX 5000 Ada |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card memory | 16 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card 4K support | Yes |
| On-board graphics card 6K support | Yes |
| Graphics card Open GL support | Yes |
Audio
| Number of built-in speakers | 2 |
|---|---|
| Speaker power | 2 W |
| Built-in subwoofer | Yes |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.1 |
| Mini DisplayPorts quantity | 1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
Performance
| Motherboard chipset | Intel HM770 |
|---|
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard backlit colour | RGB |
| Keyboard backlit zone | Per-key RGB |
Software
| Operating system installed | Windows 11 Pro |
|---|
Battery
| Battery capacity | 99 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 4 |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 330 W |
Weight & dimensions
| Weight | 3,3 kg |
|---|---|
| Width | 397 mm |
| Depth | 330 mm |
| Height | 23 mm |
Packaging content
| Mouse included | Yes |
|---|---|
| Mouse connectivity | Wireless |
Frequently asked questions
Is the MSI CreatorPro X17 X17HX A13VM-259FR good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA RTX 5000 Ada. Its card's page shows what level it handles current games at.
What is the screen of the MSI CreatorPro X17 X17HX A13VM-259FR like?
It carries a 17.3" 3840x2160 Mini LED 144Hz 100% DCI-P3 display.
Which processor and graphics card does the MSI CreatorPro X17 X17HX A13VM-259FR have?
It runs on the Intel Core i9-13980HX processor with the NVIDIA RTX 5000 Ada graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the MSI CreatorPro X17 X17HX A13VM-259FR be upgraded?
It has 4 memory slots, but it already ships with the maximum it takes (128 GB).
Which operating system does the MSI CreatorPro X17 X17HX A13VM-259FR come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the MSI CreatorPro X17 X17HX A13VM-259FR have?
According to its spec sheet: 2 × Thunderbolt 4, 3 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the MSI CreatorPro X17 X17HX A13VM-259FR have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the MSI CreatorPro X17 X17HX A13VM-259FR have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the MSI CreatorPro X17 X17HX A13VM-259FR weigh?
It weighs 3,3 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the MSI CreatorPro X17 X17HX A13VM-259FR released?
Its release date is September 2023, 3 years ago.
