Lenovo Yoga Book ZA0V0232ES
Specs
Prices
Main specs
| Processor | Intel Atom x5-Z8550 1,44GHz |
|---|---|
| Screen | 10.1" 1920x1200 IPS |
| Hard drive | 64GB eMMC |
| RAM | 4GB LPDDR3-SDRAM |
| Operating system | No OS installed |
| Graphics card | Intel HD Graphics 400 |
Alternatives with equal or higher power at a similar or lower price
Full specifications of Lenovo Yoga Book ZA0V0232ES
| Reference / Part Number | ZA0V0232ES |
|---|---|
| Also sold as | ZA0W0024FR |
| Release date | July 2017, 9 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product colour | Grey |
| Form factor | Convertible (Folder) |
| Colour name | Gunmetal Grey |
| Housing material | Aluminium,Magnesium |
| Market positioning | Business |
Image gallery
Screen
| Display diagonal | 25,6 cm |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| HD type | Full HD |
| Touch technology | Multi-touch |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Screen shape | Flat |
Processor
| Processor family | Intel Atom® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | x5-Z8550 |
| Processor frequency | 1,44 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 2,4 GHz |
| Processor cache | 2 MB |
| Processor cache type | L3 |
| Processor socket | BGA 1380 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Atom x5 series |
| Processor codename | Cherry Trail |
| Scenario Design Power (SDP) | 2 W |
| Tjunction | 90 °C |
| Maximum number of PCI Express lanes | 2 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 2x1,1x2 |
Memory
| Internal memory | 4 GB |
|---|---|
| Maximum internal memory | 4 GB |
| Internal memory type | LPDDR3-SDRAM |
| Memory clock speed | 1600 MHz |
| Memory form factor | On-board |
| Memory layout (slots x size) | 1 x 4 GB |
Storage
| Total storage capacity | 64 GB |
|---|---|
| Storage media | eMMC |
| Optical drive type | No |
| Flash memory | 64 GB |
| Flash drive interface | Flash |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 400 |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card burst frequency | 600 MHz |
| On-board graphics card dynamic frequency (max) | 600 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of execution units | 12 |
Audio
| Number of built-in speakers | 2 |
|---|---|
| Speaker power | 1,5 W |
| Built-in microphone | Yes |
| Audio decoders | Dolby Atmos |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 8 MP |
| Rear camera | Yes |
| Rear camera resolution (numeric) | 2 MP |
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Micro-USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 0 |
| DisplayPorts quantity | 0 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| Micro HDMI ports quantity | 1 |
| Headphone outputs | 0 |
| S/PDIF out port | No |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| CardBus PCMCIA slots quantity | 0 |
| CardBus PCMCIA slot type | No |
| SmartCard slot | No |
Performance
| Motherboard chipset | Intel SoC |
|---|---|
| Electronic compass | Yes |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Android 6.0 |
|---|
Processor special features
| Intel® Wireless Display (Intel® WiDi) | Yes |
|---|---|
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel 64 | Yes |
| Processor package size | 17 x 17 mm |
| Processor code | SR2KH |
| Embedded options available | No |
| Intel Secure Boot | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Boot Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 93360 |
| Conflict-Free processor | Yes |
Battery
| Battery technology | Lithium Polymer (LiPo) |
|---|---|
| Number of battery cells | 2 |
| Battery capacity | 8500 mAh |
| Battery life (max) | 15 h |
Power
| AC adapter output current | 2 A |
|---|---|
| AC adapter output voltage | 12 V |
| DC-in jack | Yes |
Certificates
| Compliance certificates | RoHS |
|---|
Weight & dimensions
| Weight | 690 g |
|---|---|
| Width | 256,6 mm |
| Depth | 170,8 mm |
| Height | 9,6 mm |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
| Power cord included | Yes |
Other features
| Maximum internal memory (64-bit) | 4 GB |
|---|
Frequently asked questions
Is the Lenovo Yoga Book ZA0V0232ES good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel HD Graphics 400. Its card's page shows what level it handles current games at.
How long does the battery of the Lenovo Yoga Book ZA0V0232ES last?
The manufacturer declares up to 15 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the Lenovo Yoga Book ZA0V0232ES like?
It carries a 10.1" 1920x1200 IPS display.
Which processor and graphics card does the Lenovo Yoga Book ZA0V0232ES have?
It runs on the Intel Atom x5-Z8550 processor with the Intel HD Graphics 400 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Lenovo Yoga Book ZA0V0232ES come with?
It comes with no operating system installed: the price does not include a license and you will have to install one yourself.
Which ports does the Lenovo Yoga Book ZA0V0232ES have?
According to its spec sheet: card reader, headphone jack (3.5 mm).
Does the Lenovo Yoga Book ZA0V0232ES have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo Yoga Book ZA0V0232ES have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the Lenovo Yoga Book ZA0V0232ES made of?
Its housing is made of Aluminium,Magnesium.
How much does the Lenovo Yoga Book ZA0V0232ES weigh?
It weighs 690 g.
When was the Lenovo Yoga Book ZA0V0232ES released?
Its release date is July 2017, 9 years ago.
