Lenovo Yoga A12 ZA1Y0017DE
Specs
Prices
Main specs
| Processor | Intel Atom x5-Z8550 1,44GHz |
|---|---|
| Screen | 12.2" 1280x800 IPS 350 nits |
| Hard drive | 32GB eMMC |
| RAM | 2GB LPDDR3-SDRAM |
| Operating system | No OS installed |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From Lenovo
From other brands
- 1
HP 14-dq1010nr 7NW46UA
$2893.923 - 2
ASUS L510MA-DH21
$2353.922 - 3
ASUS Vivobook Go 14 Flip J1400KA-DS04T
$2703.822 - 4
ASUS L510MA-DS02
$2293.821 - 5
HP 14-cf0012dx
$239.993.721 - 6
ASUS L410MA-PS04 90NB0Q15-M20800
$208.973.721 - 7
ASUS L410MA-DS04
$2193.721 - 8
HP Stream 14 14-cb164wm
$298317 - 9
ASUS L510MA-DH02
$224.892.917 - 10
ASUS Vivobook Go 14 Flip J1400KA-DS02T
$2402.818
Full specifications of Lenovo Yoga A12 ZA1Y0017DE
| Reference / Part Number | ZA1Y0017DE |
|---|---|
| Also sold as | ZA1Y0093DE, ZA1Y0092CN, ZA1Y0050CN |
| Release date | January 2017, 9 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product color | Gray |
| Form factor | Convertible (Folder) |
Image gallery
Screen
| Display diagonal | 12.2 " (31 cm) |
|---|---|
| Display resolution | 1280 x 800 pixels |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| HD type | HD |
| Touch technology | Multi-touch |
| Panel type | IPS |
| Display number of colors | 16.78 million colors |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Screen shape | Flat |
| Display brightness | 350 cd/m² |
Processor
| Processor family | Intel Atom® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | x5-Z8550 |
| Processor frequency | 1,44 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 2,4 GHz |
| Processor cache | 2 MB |
| Processor cache type | L3 |
| Processor socket | BGA 1380 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Atom x5 series |
| Processor codename | Cherry Trail |
| Scenario Design Power (SDP) | 2 W |
| Tjunction | 90 °C |
| Maximum number of PCI Express lanes | 2 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 2x1,1x2 |
Memory
| Internal memory | 2 GB |
|---|---|
| Maximum internal memory | 2 GB |
| Internal memory type | LPDDR3-SDRAM |
| Memory form factor | On-board |
Storage
| Total storage capacity | 32 GB |
|---|---|
| Storage media | eMMC |
| Optical drive type | No |
| Flash memory | 32 GB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 400 |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card burst frequency | 600 MHz |
| On-board graphics card dynamic frequency (max) | 600 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of execution units | 12 |
Audio
| Number of built-in speakers | 2 |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 1 MP |
| Front camera signal format | 720p |
Network
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 0 |
| DisplayPorts quantity | 0 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| Headphone outputs | 0 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
Performance
| Motherboard chipset | Intel SoC |
|---|---|
| Ambient light sensor | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Android 6.0.1 |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel® Wireless Display (Intel® WiDi) | Yes |
|---|---|
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel 64 | Yes |
| Processor package size | 17 x 17 mm |
| Processor code | SR2KH |
| Embedded options available | No |
| Intel Secure Boot | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Boot Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 93360 |
| Conflict-Free processor | Yes |
Battery
| Battery technology | Lithium Polymer (LiPo) |
|---|---|
| Number of battery cells | 3 |
| Battery capacity | 10500 mAh |
| Battery life (max) | 13 h |
Power
| AC adapter power | 12 W |
|---|---|
| DC-in jack | Yes |
Security
| Trusted Platform Module (TPM) | No |
|---|
Aprobaciones reguladoras
| Certificados de conformidad | RoHS |
|---|
Weight & dimensions
| Weight | 34.9 oz (990 g) |
|---|---|
| Width | 11 " (280,6 mm) |
| Depth | 8.1 " (204,8 mm) |
| Height | 0.4 " (10,9 mm) |
Packaging content
| Manual | Yes |
|---|---|
| Power cord included | Yes |
Frequently asked questions
Is the Lenovo Yoga A12 ZA1Y0017DE good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel HD Graphics 400. Its card's page shows what level it handles current games at.
How long does the battery of the Lenovo Yoga A12 ZA1Y0017DE last?
The manufacturer declares up to 13 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the Lenovo Yoga A12 ZA1Y0017DE like?
It carries a 12.2" 1280x800 IPS 350 nits display.
Which processor and graphics card does the Lenovo Yoga A12 ZA1Y0017DE have?
It runs on the Intel Atom x5-Z8550 processor with the Intel HD Graphics 400 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Lenovo Yoga A12 ZA1Y0017DE come with?
It comes with no operating system installed: the price does not include a license and you will have to install one yourself.
Which ports does the Lenovo Yoga A12 ZA1Y0017DE have?
According to its spec sheet: 1 × USB-C, card reader, headphone jack (3.5 mm).
Does the Lenovo Yoga A12 ZA1Y0017DE have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo Yoga A12 ZA1Y0017DE have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
How much does the Lenovo Yoga A12 ZA1Y0017DE weigh?
It weighs 990 g.
When was the Lenovo Yoga A12 ZA1Y0017DE released?
Its release date is January 2017, 9 years ago.
