Lenovo ThinkPad X X1 Fold 16 21ES001HUS
Specs
Prices
Main specs
| Processor | Intel Core i5 i5-1230U |
|---|---|
| Screen | 16.3" 2560x2024 OLED 100% DCI-P3 |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB LPDDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | |
| Other | Keyboard English. |
Alternatives with equal or higher power at a similar or lower price
Full specifications of Lenovo ThinkPad X X1 Fold 16 21ES001HUS
| Reference / Part Number | 21ES001HUS |
|---|---|
| Release date | October 2022, 4 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product colour | Black |
| Form factor | Convertible (Detachable) |
| Housing material | Aluminium |
Image gallery
Screen
| Display diagonal | 41,4 cm |
|---|---|
| Display resolution | 2560 x 2024 pixels |
| Touchscreen | Yes |
| Foldable display | Yes |
| Panel type | OLED |
| LED backlight | Yes |
| Native aspect ratio | 4:3 |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Contrast ratio (typical) | 1000000:1 |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Dolby Vision |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i5-1230U |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor cores | 10 |
| Processor boost frequency | 4,4 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4,4 GHz |
| Efficient-core Max Turbo Frequency | 3,3 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor base power | 9 W |
| Maximum turbo power | 29 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory clock speed | 5200 MHz |
| Memory form factor | On-board |
| Memory channels | Octa-channel |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Iris Xe Graphics |
Audio
| Audio system | Dolby Atmos |
|---|---|
| Number of built-in speakers | 3 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 4 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 5 MP |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| WWAN | Not installed |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Performance
| Motherboard chipset | Intel SoC |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | ThinkPad UltraNav |
| Keyboard layout | QWERTY |
| Keyboard language | English |
Software
| Operating system installed | Windows 11 Pro |
|---|---|
| Operating system architecture | 64-bit |
| Operating system language | English |
| Recovery operating system | Windows 10 Pro |
Processor special features
| Intel Flex Memory Access | No |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 64 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
Power
| AC adapter power | 65 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Power Delivery (USB PD) | Yes |
Security
| Fingerprint reader | Yes |
|---|---|
| Smart card reader | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | Yes |
| Password protection type | BIOS,Power on,SSD,Supervisor |
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | 5 - 43 °C |
| Operating relative humidity (H-H) | 8 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Maximum shipping altitude | 3048 m |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Certification | MIL-STD-810H |
Sustainability
| Sustainability certificates | TCO,ENERGY STAR,EPEAT Gold,ErP |
|---|
Weight & dimensions
| Weight | 1,94 kg |
|---|---|
| Weight (tablet mode) | 1,31 kg |
| Width (tablet mode) | 34,6 cm |
| Depth (tablet mode) | 27,6 cm |
| Height (tablet mode) | 8,6 mm |
Packaging content
| Stylus pen | Yes |
|---|
Frequently asked questions
Is the Lenovo ThinkPad X X1 Fold 16 21ES001HUS good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel Iris Xe Graphics. Its card's page shows what level it handles current games at.
What is the screen of the Lenovo ThinkPad X X1 Fold 16 21ES001HUS like?
It carries a 16.3" 2560x2024 OLED 100% DCI-P3 display.
Which processor and graphics card does the Lenovo ThinkPad X X1 Fold 16 21ES001HUS have?
It runs on the Intel Core i5 i5-1230U processor with the Intel Iris Xe Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Lenovo ThinkPad X X1 Fold 16 21ES001HUS come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the Lenovo ThinkPad X X1 Fold 16 21ES001HUS have?
According to its spec sheet: 2 × Thunderbolt 4, 1 × USB-C.
Does the Lenovo ThinkPad X X1 Fold 16 21ES001HUS have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the Lenovo ThinkPad X X1 Fold 16 21ES001HUS made of?
Its housing is made of Aluminium.
How much does the Lenovo ThinkPad X X1 Fold 16 21ES001HUS weigh?
It weighs 1,94 kg, a normal weight for its size: easy enough to move around.
When was the Lenovo ThinkPad X X1 Fold 16 21ES001HUS released?
Its release date is October 2022, 4 years ago.
