Lenovo ThinkPad W W541 20EF001YMD
Specs
Prices
Main specs
| Processor | Intel Core i5 i5-4210M 2,6GHz |
|---|---|
| Screen | 15.6" 1920x1080 300 nits |
| Hard drive | 500GB HDD |
| RAM | 4GB DDR3L-SDRAM |
| Operating system | Windows 7 Professional |
| Graphics card | NVIDIA Quadro K1100M 2GB |
Alternatives with equal or higher power at a similar or lower price
From Lenovo
From other brands
- 1
Acer Aspire Go 15 AG15-21P-R0RR
$389.991032 - 2
Acer Spin 5 SP513-54N-58XD
$399.951031 - 3
Acer Aspire 3 A315-24P-R7VH
$368531 - 4
ASUS Vivobook 14 X1404VA-I38128
$3884.930 - 5
ASUS Vivobook Go 15 E1504FA-AS33
$3964.930 - 6
Acer TravelMate Spin B3 TMB312RN-31-C86V
$317.84.929 - 7
Acer Aspire 3 A315-56-594W
$3954.929 - 8
Acer Aspire 3 A314-36P-3772
$3704.830 - 9
ASUS Vivobook 15 F1504ZA-AS34
$3974.829 - 10
ASUS Vivobook 14 F1402ZA-AB31
$3994.527
Full specifications of Lenovo ThinkPad W W541 20EF001YMD
| Reference / Part Number | 20EF001YMD |
|---|---|
| Also sold as | 20EF001YPB, 20EF001YGE, 20EF001YMS |
| Release date | February 2017, 9 years ago |
Design
| Product type | Mobile workstation |
|---|---|
| Product color | Black |
| Form factor | Clamshell |
Image gallery
Screen
| Display diagonal | 15.6 " (39,6 cm) |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Screen shape | Flat |
| Display brightness | 300 cd/m² |
| Pantalla dual | No |
| Contrast ratio (typical) | 500:1 |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i5-4210M |
| Processor frequency | 2,6 GHz |
| Generación del procesador | Intel Core i5-4xxx |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 3,2 GHz |
| System bus rate | 5 GT/s |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Processor socket | PGA946 |
| Processor lithography | 22 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Core i5-4200 Mobile series |
| Processor codename | Haswell |
| Bus type | DMI |
| FSB Parity | No |
| Stepping | C0 |
| Thermal Design Power (TDP) | 37 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16,2x8,1x8+2x4 |
| ECC supported by processor | No |
Memory
| Internal memory | 4 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | DDR3L-SDRAM |
| Memory clock speed | 1600 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 4x SO-DIMM |
Storage
| Total storage capacity | 500 GB |
|---|---|
| Storage media | HDD |
| Optical drive type | DVD±RW |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| HDD interface | SATA III |
| HDD size | 2.5 " |
| Card reader integrated | Yes |
| Compatible memory cards | MMC,SD,SDHC,SDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA® Quadro® K1100M |
| On-board graphics card model | Intel® HD Graphics 4600 |
| Discrete graphics card memory | 2 GB |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card base frequency | 400 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| Maximum on-board graphics card memory | 1,74 GB |
| On-board graphics card DirectX version | 11.1 |
| On-board graphics card OpenGL version | 4.3 |
| On-board graphics card ID | 0x416 |
| Graphics card Open GL support | Yes |
Audio
| Audio chip | Realtek ALC3232 |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 1 W |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
Network
| Wi-Fi | Yes |
|---|---|
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 0 |
| Mini DisplayPorts quantity | 1 |
| DVI port | No |
| Mini DisplayPort/Thunderbolt combo port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Thunderbolt ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| Headphone outputs | 0 |
| S/PDIF out port | No |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Docking connector | Yes |
| ExpressCard slot | Yes |
| CardBus PCMCIA slots quantity | 0 |
| CardBus PCMCIA slot type | No |
| USB Sleep-and-Charge | Yes |
| USB Sleep-and-Charge ports | 1 |
Performance
| Motherboard chipset | Intel® QM87 |
|---|
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | ThinkPad UltraNav |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
| Full-size keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 7 Professional |
|---|---|
| Operating system architecture | 64-bit |
| Recovery operating system | Windows 10 Pro |
Processor special features
| Intel® Wireless Display (Intel® WiDi) | Yes |
|---|---|
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Built-in Visuals Technology | Yes |
| Intel HD Graphics | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | No |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | No |
| Intel® Smart Cache | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Demand Based Switching | No |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 37.5 x 37.5 x 4.7 mm |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Processor code | SR1L4 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Dual Display Capable Technology | No |
| Intel FDI Technology | No |
| Intel Rapid Storage Technology | No |
| Intel Fast Memory Access | No |
| Processor ARK ID | 81012 |
| Conflict-Free processor | Yes |
Battery
| Battery capacity | 99,9 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 9 |
| Battery life (max) | 11,1 h |
Power
| AC adapter power | 135 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| DC-in jack | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Fingerprint reader | Yes |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | HDD,Power on,Supervisor |
Aprobaciones reguladoras
| Certificados de conformidad | RoHS |
|---|
Sustainability
| Sustainability certificates | EPEAT Gold,ENERGY STAR |
|---|
Weight & dimensions
| Weight | 6 lbs (2,7 kg) |
|---|---|
| Width | 14.8 " (376,6 mm) |
| Depth | 9.8 " (248,1 mm) |
| Height (front) | 1.1 " (2,79 cm) |
| Height (rear) | 1.2 " (2,95 cm) |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
| Quick start guide | Yes |
| Power cord included | Yes |
Other features
| Intel® Virtualization Technology (Intel® VT) | VT-d,VT-x |
|---|---|
| Intel segment tagging | Professional |
Frequently asked questions
Is the Lenovo ThinkPad W W541 20EF001YMD good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA Quadro K1100M. Its card's page shows what level it handles current games at.
How long does the battery of the Lenovo ThinkPad W W541 20EF001YMD last?
The manufacturer declares up to 11,1 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the Lenovo ThinkPad W W541 20EF001YMD like?
It carries a 15.6" 1920x1080 300 nits display.
Which processor and graphics card does the Lenovo ThinkPad W W541 20EF001YMD have?
It runs on the Intel Core i5 i5-4210M processor with the NVIDIA Quadro K1100M graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the Lenovo ThinkPad W W541 20EF001YMD be upgraded?
Yes: it has 4 memory slots and takes up to 32 GB according to the manufacturer (it ships with 4GB).
Which operating system does the Lenovo ThinkPad W W541 20EF001YMD come with?
It comes with Windows 7 Professional preinstalled.
Which ports does the Lenovo ThinkPad W W541 20EF001YMD have?
According to its spec sheet: 2 × USB-A, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the Lenovo ThinkPad W W541 20EF001YMD have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo ThinkPad W W541 20EF001YMD have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the Lenovo ThinkPad W W541 20EF001YMD weigh?
It weighs 2,7 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the Lenovo ThinkPad W W541 20EF001YMD released?
Its release date is February 2017, 9 years ago.
