+10
Lenovo ThinkPad T T14 21AH001DUS
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 14" 1920x1200 IPS 300 nits 45% NTSC |
| Hard drive | 1TB SSD M.2 |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | |
| Other | Keyboard US English. |
Other configurations of this model
| Score | Power | Price ▲ | Processor | Graphics card | Screen | RAM | Operating system | Battery |
|---|---|---|---|---|---|---|---|---|
| 8.3 | 46 | $999.99 | Intel Core i5-1335U | Intel Iris Xe Graphics | 1920x1200 IPS 300 nits | DDR5-SDRAM | Windows 11 Pro | |
| 7.2 | 40 | $1099.99 | Intel Core i7-10510U | Intel UHD Graphics | 1920x1080 WVA 400 nits | DDR4-SDRAM | Windows 10 Pro | 16,5 h |
| 6.9 | 43 | $1999.99 | AMD Ryzen 5 PRO 5650U | AMD Radeon Graphics | 1920x1080 IPS 300 nits | DDR4-SDRAM | Windows 11 Pro | 13 h |
Full specifications of Lenovo ThinkPad T T14 21AH001DUS
| Reference / Part Number | 21AH001DUS |
|---|---|
| Release date | June 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Black |
| Form factor | Clamshell |
| Color name | Thunder Black |
Image gallery
Screen
| Display diagonal | 14 " (35,6 cm) |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | Yes |
| HD type | WUXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display brightness | 300 cd/m² |
| RGB color space | NTSC |
| Color gamut | 45 % |
| Contrast ratio (typical) | 700:1 |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-1260P |
| Generación del procesador | Intel Core i7-12xxx |
| Processor cores | 12 |
| Processor boost frequency | 4,7 GHz |
| Processor cache | 18 MB |
| Configurable TDP-down | 20 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 48 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory form factor | On-board + SO-DIMM |
| Memory slots | 1x SO-DIMM |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | NVMe,PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Iris Xe Graphics |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
Audio
| Audio chip | Realtek ALC3287 |
|---|---|
| Audio system | Dolby Audio |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1920 x 1080 pixels |
| Front camera HD type | Full HD |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,100 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Número de puertos Thunderbolt 4 | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery | Yes |
| USB Sleep-and-Charge | Yes |
| USB Sleep-and-Charge ports | 1 |
Performance
| Motherboard chipset | Intel SoC |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | ThinkPad UltraNav |
| Keyboard language | US English |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
Software
| Operating system installed | Windows 11 Pro |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 52,5 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Fast charging | Yes |
Power
| AC adapter power | 65 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Fingerprint reader | Yes |
| Smart card reader | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | Yes |
| Password protection type | Power on,Supervisor |
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | 5 - 43 °C |
| Operating relative humidity (H-H) | 8 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
Aprobaciones reguladoras
| Compliance certificates | RoHS |
|---|---|
| Certification | MIL-STD-810H, ErP Lot 3 |
Sustainability
| Sustainability certificates | TCO,ENERGY STAR,EPEAT Gold |
|---|
Weight & dimensions
| Weight | 2.9 lbs (1,32 kg) |
|---|---|
| Width | 12.5 " (317,7 mm) |
| Depth | 8.9 " (226,9 mm) |
| Height | 0.7 " (17,9 mm) |
Alternatives with equal or higher power at a similar or lower price
Frequently asked questions
Is the Lenovo ThinkPad T T14 21AH001DUS good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel Iris Xe Graphics. Its card's page shows what level it handles current games at.
What is the screen of the Lenovo ThinkPad T T14 21AH001DUS like?
It carries a 14" 1920x1200 IPS 300 nits 45% NTSC display.
Which processor and graphics card does the Lenovo ThinkPad T T14 21AH001DUS have?
It runs on the Intel Core i7-1260P processor with the Intel Iris Xe Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the Lenovo ThinkPad T T14 21AH001DUS be upgraded?
Yes: it has 1 memory slot and takes up to 48 GB according to the manufacturer (it ships with 16GB).
Which operating system does the Lenovo ThinkPad T T14 21AH001DUS come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the Lenovo ThinkPad T T14 21AH001DUS have?
According to its spec sheet: 2 × Thunderbolt 4, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), headphone jack (3.5 mm).
Does the Lenovo ThinkPad T T14 21AH001DUS have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo ThinkPad T T14 21AH001DUS have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
How much does the Lenovo ThinkPad T T14 21AH001DUS weigh?
It weighs 1,32 kg: one of the light ones, easy to carry every day.
When was the Lenovo ThinkPad T T14 21AH001DUS released?
Its release date is June 2022, 4 years ago.
