Lenovo ThinkPad P P1 Gen 3 20TJS0B100
Specs
Prices
Main specs
| Processor | Intel Xeon W-10855M 2,8GHz |
|---|---|
| Screen | 15.6" 3840x2160 100% |
| Hard drive | 1TB SSD M.2 |
| RAM | 32GB DDR4-SDRAM |
| Operating system | Windows 10 Pro for Workstations |
| Graphics card | NVIDIA Quadro T2000 4GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of Lenovo ThinkPad P P1 Gen 3 20TJS0B100
| Reference / Part Number | 20TJS0B100 |
|---|---|
| Also sold as | 20TJS0B100-MOBI_AA, 20TJS0B100-MOBI_AC, 20TJS0B100-MOBI_AD, 20TJS0B100-MOBI_AB, 20TJS0B100-MOBI_AF |
| Release date | August 2025, 1 year ago |
Design
| Product type | Mobile workstation |
|---|---|
| Product colour | Black |
| Form factor | Clamshell |
| Housing material | Acrylonitrile butadiene styrene (ABS),Aluminium,Carbon fibre,Polycarbonate (PC),Polyphenylene sulfide (PPS) |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Colour gamut | 100 % |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Dolby Vision |
Processor
| Processor family | Intel® Xeon® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | W-10855M |
| Processor frequency | 2,8 GHz |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor boost frequency | 5,1 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2933 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
| Memory channels | Dual-channel |
| ECC | Yes |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express |
| NVMe | Yes |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA Quadro T2000 |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| NVIDIA Max-Q | Yes |
Audio
| Audio chip | Realtek ALC3286 |
|---|---|
| Audio system | Dolby Atmos |
| Number of built-in speakers | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | Yes |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Mobile network generation | 4G |
| 4G standard | LTE |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| WLAN controller manufacturer | Intel |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| WWAN | Installed |
| WWAN controller | Fibocom L860-GL |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Thunderbolt 3 ports quantity | 2 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
| USB Sleep-and-Charge ports | 1 |
Performance
| Motherboard chipset | Intel WM490 |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | ThinkPad UltraNav |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
Software
| Operating system installed | Windows 10 Pro for Workstations |
|---|---|
| Operating system architecture | 64-bit |
| Operating system language | DEU,DUT,ENG,FRE,ITA |
Battery
| Battery capacity | 80 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Battery life (max) | 15,9 h |
Power
| USB Type-C charging port | Yes |
|---|---|
| USB Power Delivery (USB PD) | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Fingerprint reader | Yes |
| Smart card reader | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | Yes |
| Password protection type | Power on,Supervisor,HDD |
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | 5 - 43 °C |
| Operating relative humidity (H-H) | 8 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Maximum shipping altitude | 3048 m |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Certification | MIL-STD-810G |
Sustainability
| Sustainability certificates | ENERGY STAR,EPEAT Gold |
|---|
Weight & dimensions
| Width | 361,8 mm |
|---|---|
| Depth | 245,7 mm |
Packaging content
| AC adapter included | Yes |
|---|
Frequently asked questions
Is the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA Quadro T2000. Its card's page shows what level it handles current games at.
How long does the battery of the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 last?
The manufacturer declares up to 15,9 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 like?
It carries a 15.6" 3840x2160 100% display.
Which processor and graphics card does the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 have?
It runs on the Intel Xeon W-10855M processor with the NVIDIA Quadro T2000 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 be upgraded?
Yes: it has 2 memory slots and takes up to 64 GB according to the manufacturer (it ships with 32GB).
Which operating system does the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 come with?
It comes with Windows 10 Pro for Workstations preinstalled.
Which ports does the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 have?
According to its spec sheet: 2 × Thunderbolt 3, 2 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
What material is the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 made of?
Its housing is made of Acrylonitrile butadiene styrene (ABS),Aluminium,Carbon fibre,Polycarbonate (PC),Polyphenylene sulfide (PPS).
When was the Lenovo ThinkPad P P1 Gen 3 20TJS0B100 released?
Its release date is August 2025, 1 year ago.
