Lenovo ThinkBook 13x G2 IAP 21AT0010US
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 13.3" 2560x1600 IPS 400 nits 100% sRGB |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB LPDDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | |
| Other | Keyboard US English. |
Alternatives with equal or higher power at a similar or lower price
From Lenovo
From other brands
Full specifications of Lenovo ThinkBook 13x G2 IAP 21AT0010US
| Reference / Part Number | 21AT0010US |
|---|---|
| Release date | March 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Grey |
| Form factor | Clamshell |
| Colour name | Cloud Grey |
Image gallery
Screen
| Display diagonal | 33,8 cm |
|---|---|
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| HD type | WQXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Display surface | Gloss |
| Display brightness | 400 cd/m² |
| RGB colour space | sRGB |
| Colour gamut | 100 % |
| Contrast ratio (typical) | 1200:1 |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Dolby Vision |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-1255U |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor cores | 10 |
| Processor boost frequency | 4,7 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4,7 GHz |
| Efficient-core Max Turbo Frequency | 3,5 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Configurable TDP-down | 12 W |
| Processor base power | 15 W |
| Maximum turbo power | 55 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | On-board |
| Memory channels | Dual-channel |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | No |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Iris™ Graphics |
Audio
| Audio chip | Realtek ALC3306 |
|---|---|
| Audio system | Dolby Atmos |
| Number of built-in speakers | 2 |
| Speakers manufacturer | Harman Kardon |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Performance
| Motherboard chipset | Intel SoC |
|---|---|
| Ambient light sensor | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
| Keyboard language | US English |
Software
| Operating system installed | Windows 11 Pro |
|---|---|
| Operating system architecture | 64-bit |
| Operating system language | English |
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 56 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Battery life (max) | 11,4 h |
| Fast charging | Yes |
Power
| AC adapter power | 65 W |
|---|---|
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Power Delivery (USB PD) | Yes |
Security
| Fingerprint reader | Yes |
|---|---|
| Windows Hello | Yes |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | Yes |
| Password protection type | Power on,Supervisor,SSD |
Operational conditions
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | 5 - 43 °C |
| Operating relative humidity (H-H) | 8 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Maximum shipping altitude | 3048 m |
Certificates
| Certification | EPEAT™ Silver ENERGY STAR® 8.0 ErP Lot 3 FSC certified carton TCO Certified RoHS compliant Low-VOC MIL-STD-810H TÜV |
|---|
Weight & dimensions
| Weight | 1,2 kg |
|---|---|
| Width | 296 mm |
| Depth | 209 mm |
| Height | 12,9 mm |
Frequently asked questions
Is the Lenovo ThinkBook 13x G2 IAP 21AT0010US good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel Iris Xe Graphics. Its card's page shows what level it handles current games at.
How long does the battery of the Lenovo ThinkBook 13x G2 IAP 21AT0010US last?
The manufacturer declares up to 11,4 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the Lenovo ThinkBook 13x G2 IAP 21AT0010US like?
It carries a 13.3" 2560x1600 IPS 400 nits 100% sRGB display.
Which processor and graphics card does the Lenovo ThinkBook 13x G2 IAP 21AT0010US have?
It runs on the Intel Core i7-1255U processor with the Intel Iris Xe Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Lenovo ThinkBook 13x G2 IAP 21AT0010US come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the Lenovo ThinkBook 13x G2 IAP 21AT0010US have?
According to its spec sheet: 2 × Thunderbolt 4, headphone jack (3.5 mm).
Does the Lenovo ThinkBook 13x G2 IAP 21AT0010US have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Lenovo ThinkBook 13x G2 IAP 21AT0010US have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the Lenovo ThinkBook 13x G2 IAP 21AT0010US weigh?
It weighs 1,2 kg: one of the light ones, easy to carry every day.
When was the Lenovo ThinkBook 13x G2 IAP 21AT0010US released?
Its release date is March 2022, 4 years ago.
