HP ZBook Studio G5 6TW44EA#ABH
Specs
Prices
Main specs
| Processor | Intel Core i9 i9-9880H 2,3GHz |
|---|---|
| Screen | 15.6" 3840x2160 IPS 400 nits |
| Hard drive | 512GB SSD |
| RAM | 32GB DDR4-SDRAM |
| Operating system | Windows 10 Pro |
| Graphics card | NVIDIA Quadro P2000 4GB GDDR5 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of HP ZBook Studio G5 6TW44EA#ABH
| Reference / Part Number | 6TW44EA#ABH |
|---|---|
| Release date | February 2020, 6 years ago |
Design
| Product type | Mobile workstation |
|---|---|
| Product colour | Silver |
| Form factor | Clamshell |
| Market positioning | Business |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display brightness | 400 cd/m² |
Processor
| Processor family | Intel® Core™ i9 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i9-9880H |
| Processor frequency | 2,3 GHz |
| Processor generation | 9th gen Intel® Core™ i9 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4,8 GHz |
| System bus rate | 8 GT/s |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1440 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Coffee Lake |
| Thermal Design Power (TDP) | 45 W |
| Configurable TDP-down | 35 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16,2x8,1x8+2x4 |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | NVMe,PCI Express |
| NVMe | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD,SDHC,SDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA® Quadro® P2000 |
| On-board graphics card model | Intel® UHD Graphics 630 |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR5 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3E9B |
Audio
| Audio system | Bang & Olufsen |
|---|---|
| Number of built-in speakers | 2 |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| WLAN controller model | Intel Dual Band Wireless-AC 9560 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.0 |
| Thunderbolt 3 ports quantity | 2 |
| Combo headphone/mic port | Yes |
Performance
| Ambient light sensor | Yes |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Clickpad |
| Keyboard layout | QWERTY |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
Software
| Operating system installed | Windows 10 Pro |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel® My WiFi Technology (Intel® MWT) | Yes |
|---|---|
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 42 x 28 mm |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 192987 |
Battery
| Battery capacity | 95,6 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 6 |
Power
| AC adapter power | 150 W |
|---|---|
| DC-in jack | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 2 kg |
|---|---|
| Width | 360 mm |
| Depth | 254 mm |
| Height | 8,8 mm |
| Height (front) | 1,74 cm |
Frequently asked questions
Is the HP ZBook Studio G5 6TW44EA#ABH good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA Quadro P2000. Its card's page shows what level it handles current games at.
What is the screen of the HP ZBook Studio G5 6TW44EA#ABH like?
It carries a 15.6" 3840x2160 IPS 400 nits display.
Which processor and graphics card does the HP ZBook Studio G5 6TW44EA#ABH have?
It runs on the Intel Core i9 i9-9880H processor with the NVIDIA Quadro P2000 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the HP ZBook Studio G5 6TW44EA#ABH be upgraded?
It has 2 memory slots, but it already ships with the maximum it takes (32 GB).
Which operating system does the HP ZBook Studio G5 6TW44EA#ABH come with?
It comes with Windows 10 Pro preinstalled.
Which ports does the HP ZBook Studio G5 6TW44EA#ABH have?
According to its spec sheet: 2 × Thunderbolt 3, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the HP ZBook Studio G5 6TW44EA#ABH have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the HP ZBook Studio G5 6TW44EA#ABH have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the HP ZBook Studio G5 6TW44EA#ABH weigh?
It weighs 2 kg, a normal weight for its size: easy enough to move around.
When was the HP ZBook Studio G5 6TW44EA#ABH released?
Its release date is February 2020, 6 years ago.
