HP ZBook 14u G5 3YE08UT
Specs
Prices
Main specs
| Processor | Intel Core i7-8550U 1,80GHz |
|---|---|
| Screen | 14" 1920x1080 IPS |
| Hard drive | 512GB SSD |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 10 Pro |
| Graphics card | AMD Radeon Pro WX 3100 2GB GDDR5 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of HP ZBook 14u G5 3YE08UT
| Reference / Part Number | 3YE08UT |
|---|---|
| Release date | March 2018, 8 years ago |
Design
| Product colour | Silver |
|---|---|
| Product type | Mobile workstation |
| Form factor | Clamshell |
| Country of origin | China |
Image gallery
Screen
| Display diagonal | 35,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| Panel type | IPS |
| HD type | Full HD |
| Aspect ratio | 16:9 |
| LED backlight | Yes |
Processor
| Processor family | 8th gen Intel® Core™ i7 |
|---|---|
| Processor model | i7-8550U |
| Processor frequency | 1,80 GHz |
| Processor cores | 4 |
| Processor boost frequency | 4,00 GHz |
| Processor threads | 8 |
| System bus rate | 4 GT/s |
| Processor cache | 8 MB |
| Processor socket | BGA 1356 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Kaby Lake R |
| Bus type | OPI |
| Stepping | Y0 |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-down frequency | 800 MHz |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 12 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
| ECC supported by processor | No |
Memory
| Internal memory | 16 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
| Memory clock speed | 2400 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Card reader integrated | Yes |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Compatible memory cards | SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card model | Intel® UHD Graphics 620 |
| Discrete graphics card model | AMD Radeon Pro WX 3100 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x5917 |
| Discrete graphics card memory | 2 GB |
| Discrete graphics memory type | GDDR5 |
Audio
| Audio system | Bang & Olufsen |
|---|---|
| Number of built-in speakers | 2 |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Bluetooth | Yes |
|---|---|
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| WLAN controller model | Intel Dual Band Wireless-AC 8265 |
| Antenna type | 2x2 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Charging port type | DC-in jack |
| SmartCard slot | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 Pro |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel® My WiFi Technology (Intel® MWT) | Yes |
|---|---|
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 42 x 24 mm |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 122589 |
| Conflict-Free processor | Yes |
Brand-specific features
| HP JumpStart | Yes |
|---|---|
| HP Sure Connect | Yes |
| HP speaker type | HP Dual Speakers |
| HP Smart AC Adapter | Yes |
| HP Management tools | HP BIOSphere with Sure Start Gen3; HP Client Security Suite Gen 3; HP Device Access Manager; HP FingerPrint Sensor; HP Power On Authentication; HP Security Manager |
| HP Software provided | HP ePrint Driver + JetAdvantage; HP Hotkey Support; HP Noise Cancellation Software; HP Performance Advisor; HP Recovery Manager; HP Remote Graphics Software; HP Secure Erase; HP Support Assistant; HP Velocity; HP WorkWise (requires Bluetooth),HP Mobile Connect Pro; Native Miracast support |
| HP segment | Business |
Battery
| Battery capacity | 50 Wh |
|---|---|
| Number of battery cells | 3 |
| Battery life (max) | 10 h |
Power
| AC adapter power | 65 W |
|---|
Aprobaciones reguladoras
| Certificado Energy Star | Yes |
|---|
Weight & dimensions
| Weight | 1,48 kg |
|---|---|
| Width | 326 mm |
| Depth | 234,3 mm |
| Height | 17,9 mm |
Other features
| AC adapter included | Yes |
|---|
Frequently asked questions
Is the HP ZBook 14u G5 3YE08UT good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated AMD Radeon Pro WX 3100. Its card's page shows what level it handles current games at.
How long does the battery of the HP ZBook 14u G5 3YE08UT last?
The manufacturer declares up to 10 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the HP ZBook 14u G5 3YE08UT like?
It carries a 14" 1920x1080 IPS display.
Which processor and graphics card does the HP ZBook 14u G5 3YE08UT have?
It runs on the Intel Core i7-8550U processor with the AMD Radeon Pro WX 3100 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the HP ZBook 14u G5 3YE08UT be upgraded?
Yes: it has 2 memory slots and takes up to 32 GB according to the manufacturer (it ships with 16GB).
Which operating system does the HP ZBook 14u G5 3YE08UT come with?
It comes with Windows 10 Pro preinstalled.
Which ports does the HP ZBook 14u G5 3YE08UT have?
According to its spec sheet: 1 × Thunderbolt 3, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the HP ZBook 14u G5 3YE08UT have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the HP ZBook 14u G5 3YE08UT have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the HP ZBook 14u G5 3YE08UT weigh?
It weighs 1,48 kg: one of the light ones, easy to carry every day.
When was the HP ZBook 14u G5 3YE08UT released?
Its release date is March 2018, 8 years ago.
