HP EliteBook 800 860 G10 86S98PA
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 16" 1920x1200 IPS 250 nits 45% NTSC |
| Hard drive | 256GB SSD |
| RAM | 16GB DDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | Not available |
Full specifications of HP EliteBook 800 860 G10 86S98PA
| Reference / Part Number | 86S98PA |
|---|---|
| Release date | June 2023, 3 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Silver |
| Form factor | Clamshell |
| Market positioning | Premium |
| Introduction year | 2023 |
| Original brand name | HP |
Image gallery
Screen
| Display diagonal | 40,6 cm |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | No |
| HD type | WUXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Anti-glare screen | Yes |
| Display brightness | 250 cd/m² |
| Display diagonal (metric) | 40,6 cm |
| RGB colour space | NTSC |
| Colour gamut | 45 % |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-1355U |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor boost frequency | 5 GHz |
| Efficient-core Max Turbo Frequency | 3,7 GHz |
| Performance-core Max Turbo Frequency | 5 GHz |
| Processor threads | 12 |
| Processor cores | 10 |
| Performance cores | 2 |
| Efficient cores | 8 |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Configurable TDP-down | 12 W |
| Processor base power | 15 W |
| Maximum turbo power | 55 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5200 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 2x SO-DIMM |
| ECC | No |
| Non-ECC | Yes |
| Number of free internal memory expansion slots | 2 |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express |
| NVMe | Yes |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Iris Xe Graphics |
Audio
| Audio system | B&O PLAY |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speakers manufacturer | Bang & Olufsen |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Infrared (IR) camera | Yes |
| Privacy camera | Yes |
Network
| Mobile network connection | Yes |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| Charging port type | USB Type-C |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery | Yes |
Performance
| Ambient light sensor | Yes |
|---|
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Clickpad |
| Keyboard backlit | Yes |
| Spill-resistant keyboard | Yes |
| Full-size keyboard | Yes |
| Input device model | HP Premium Keyboard |
| Keyboard special features | Spill-resistant |
Software
| Operating system installed | Windows 11 Pro |
|---|
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Brand-specific features
| HP speaker type | HP Quad Speakers |
|---|---|
| HP Connection Optimizer | Yes |
| HP Support Assistant | Yes |
| HP front camera | HP Webcam |
| HP segment | Business |
Battery
| Battery capacity | 51 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
Power
| AC adapter power | 65 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
Security
| Fingerprint reader | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Password protection | Yes |
| Password protection type | BIOS,Power on,User |
Certificates
| Low halogen | Yes |
|---|
Sustainability
| Sustainability compliance | Yes |
|---|---|
| Sustainability certificates | ENERGY STAR,GS mark,TCO |
Weight & dimensions
| Weight | 1,73 kg |
|---|---|
| Width | 358,7 mm |
| Depth | 251 mm |
| Height | 19,2 mm |
Packaging data
| Package width | 69 mm |
|---|---|
| Package depth | 552 mm |
| Package height | 345 mm |
Other features
| Number of speakers | 2 |
|---|
Frequently asked questions
Is the HP EliteBook 800 860 G10 86S98PA good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated Not available. Its card's page shows what level it handles current games at.
What is the screen of the HP EliteBook 800 860 G10 86S98PA like?
It carries a 16" 1920x1200 IPS 250 nits 45% NTSC display.
Which processor and graphics card does the HP EliteBook 800 860 G10 86S98PA have?
It runs on the Intel Core i7-1355U processor with the Not available graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the HP EliteBook 800 860 G10 86S98PA be upgraded?
Yes: it has 2 memory slots and takes up to 64 GB according to the manufacturer (it ships with 16GB).
Which operating system does the HP EliteBook 800 860 G10 86S98PA come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the HP EliteBook 800 860 G10 86S98PA have?
According to its spec sheet: 2 × Thunderbolt 4, 2 × USB-A, 1 × HDMI, headphone jack (3.5 mm).
Does the HP EliteBook 800 860 G10 86S98PA have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the HP EliteBook 800 860 G10 86S98PA have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the HP EliteBook 800 860 G10 86S98PA weigh?
It weighs 1,73 kg, a normal weight for its size: easy enough to move around.
When was the HP EliteBook 800 860 G10 86S98PA released?
Its release date is June 2023, 3 years ago.
