Honor MagicBook 16 5301ABFX
Specs
Prices
Main specs
| Processor | AMD Ryzen 5 5600H 3,3GHz |
|---|---|
| Screen | 16.1" 1920x1080 IPS 100% sRGB |
| Hard drive | 512GB SSD |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 11 |
| Graphics card | AMD Radeon Vega 8 |
| Other | Keyboard English. |
Alternatives with equal or higher power at a similar or lower price
Full specifications of Honor MagicBook 16 5301ABFX
| Reference / Part Number | 5301ABFX |
|---|---|
| Release date | July 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Grey |
| Form factor | Clamshell |
| Colour name | Space Grey |
| Housing material | Aluminium |
| Introduction year | 2021 |
| Refurbished | No |
Image gallery
Screen
| Display diagonal | 40,9 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | IPS |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| Pixel density | 137 ppi |
| RGB colour space | sRGB |
| Colour gamut | 100 % |
Processor
| Processor family | AMD Ryzen™ 5 |
|---|---|
| Processor manufacturer | AMD |
| Processor model | 5600H |
| Processor frequency | 3,3 GHz |
| Processor generation | AMD Ryzen 5000 Series |
| Processor cores | 6 |
| Processor boost frequency | 4,2 GHz |
| Processor cache | 16 MB |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory channels | Dual-channel |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | AMD Radeon Vega 8 |
| On-board GPU manufacturer | AMD |
| On-board graphics card family | AMD Radeon Vega Graphics |
Audio
| Audio system | Nahimic Audio |
|---|---|
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTY |
| Keyboard language | English |
Software
| Operating system installed | Windows 11 |
|---|
Battery
| Battery capacity | 56 Wh |
|---|---|
| Continuous video playback time | 11,5 h |
| Removable battery | No |
| Battery recharge time | 1,5 h |
| Fast charging time (50%) | 30 min |
| Fast charging time (90%) | 80 min |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 65 W |
Security
| Fingerprint reader | Yes |
|---|
Weight & dimensions
| Weight | 1,84 kg |
|---|---|
| Width | 368 mm |
| Depth | 236 mm |
| Height | 18,2 mm |
Frequently asked questions
Is the Honor MagicBook 16 5301ABFX good for gaming?
This laptop was not built for gaming: it relies on the integrated AMD Radeon Vega 8. Its card's page shows what level it handles current games at.
What is the screen of the Honor MagicBook 16 5301ABFX like?
It carries a 16.1" 1920x1080 IPS 100% sRGB display.
Which processor and graphics card does the Honor MagicBook 16 5301ABFX have?
It runs on the AMD Ryzen 5 5600H processor with the AMD Radeon Vega 8 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Honor MagicBook 16 5301ABFX come with?
It comes with Windows 11 preinstalled.
Which ports does the Honor MagicBook 16 5301ABFX have?
According to its spec sheet: 2 × USB-C, 2 × USB-A, 1 × HDMI, headphone jack (3.5 mm).
Does the Honor MagicBook 16 5301ABFX have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
What material is the Honor MagicBook 16 5301ABFX made of?
Its housing is made of Aluminium.
How much does the Honor MagicBook 16 5301ABFX weigh?
It weighs 1,84 kg, a normal weight for its size: easy enough to move around.
When was the Honor MagicBook 16 5301ABFX released?
Its release date is July 2022, 4 years ago.
