GIGABYTE AORUS 16X ASG-63UKC65SH
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 16" 2560x1600 165Hz 100% sRGB |
| Hard drive | 2TB SSD M.2 |
| RAM | 32GB DDR5-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | NVIDIA GeForce RTX 4070 8GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From GIGABYTE
From other brands
Full specifications of GIGABYTE AORUS 16X ASG-63UKC65SH
| Reference / Part Number | AORUS 16X ASG-63UKC65SH |
|---|---|
| Release date | January 2024, 2 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Gray |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Año de introducción | 2024 |
| Country of origin | China |
Image gallery
Screen
| Display diagonal | 16 " (40,6 cm) |
|---|---|
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| HD type | WQXGA |
| Native aspect ratio | 16:10 |
| RGB color space | sRGB |
| Color gamut | 100 % |
| Maximum refresh rate | 165 Hz |
Processor
| Processor family | Intel® Core™ i9 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i9-14900HX |
| Generación del procesador | Intel Core i9-14xxx |
| Processor cores | 24 |
| Processor boost frequency | 5,8 GHz |
| Núcleos de rendimiento | 8 |
| Núcleos de eficiencia | 16 |
| Frecuencia turbo máxima del núcleo de rendimiento | 5.8 |
| Frecuencia turbo máxima del núcleo de eficiencia | 4.1 |
| Frecuencia base de núcleo de rendimiento | 2.2 |
| Frecuencia de aceleración de núcleo eficiente | 1.6 |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Potencia base del procesador | 55 |
| Potencia turbo máxima | 157 |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 2 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 4070 |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
| On-board graphics card family | Intel® UHD Graphics |
Audio
| Audio system | Dolby Atmos |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1920 x 1080 pixels |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.1 |
| Número de puertos Thunderbolt 4 | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard backlit color | RGB |
| Zona retroiluminada del teclado | 3-zone RGB |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
Battery
| Battery capacity | 99 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 4 |
| Battery weight | 12.3 oz (348 g) |
Power
| AC adapter power | 240 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| DC-in jack | Yes |
Security
| Face recognition | Yes |
|---|---|
| Windows Hello | Yes |
| Trusted Platform Module (TPM) | Yes |
Weight & dimensions
| Weight | 5.1 lbs (2,3 kg) |
|---|---|
| Width | 14 " (356 mm) |
| Depth | 10 " (254 mm) |
| Height (front) | 0.8 " (2 cm) |
| Height (rear) | 1.1 " (2,7 cm) |
Packaging data
| Package width | 3.7 " (95 mm) |
|---|---|
| Package depth | 15.7 " (400 mm) |
| Package height | 12.4 " (315 mm) |
| Package weight | 8.7 lbs (3,94 kg) |
Logistics data
| Quantity per shipping (inner) case | 1 pc(s) |
|---|
Other features
| Batteries included | Yes |
|---|---|
| Warranty period | 2 year(s) |
Packaging content
| Number of batteries | 1 |
|---|
Frequently asked questions
Is the GIGABYTE AORUS 16X ASG-63UKC65SH good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 4070. Its card's page shows what level it handles current games at.
What is the screen of the GIGABYTE AORUS 16X ASG-63UKC65SH like?
It carries a 16" 2560x1600 165Hz 100% sRGB display.
Which processor and graphics card does the GIGABYTE AORUS 16X ASG-63UKC65SH have?
It runs on the Intel Core i9-14900HX processor with the NVIDIA GeForce RTX 4070 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the GIGABYTE AORUS 16X ASG-63UKC65SH be upgraded?
It has 2 memory slots, but it already ships with the maximum it takes (32 GB).
Which operating system does the GIGABYTE AORUS 16X ASG-63UKC65SH come with?
It comes with Windows 11 Home preinstalled.
Which ports does the GIGABYTE AORUS 16X ASG-63UKC65SH have?
According to its spec sheet: 1 × Thunderbolt 4, 1 × USB-C, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the GIGABYTE AORUS 16X ASG-63UKC65SH have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the GIGABYTE AORUS 16X ASG-63UKC65SH have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the GIGABYTE AORUS 16X ASG-63UKC65SH weigh?
It weighs 2,3 kg, a normal weight for its size: easy enough to move around.
When was the GIGABYTE AORUS 16X ASG-63UKC65SH released?
Its release date is January 2024, 2 years ago.
