DELL XPS 15 9575 9575-3795
Specs
Prices
Main specs
| Processor | Intel Core i5 i5-8305G 2,8GHz |
|---|---|
| Screen | 15.6" 1920x1080 IPS 400 nits |
| Hard drive | 256GB SSD M.2 |
| RAM | 8GB DDR4-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card | AMD Radeon RX Vega M GL HBM2 |
Alternatives with equal or higher power at a similar or lower price
From DELL
Full specifications of DELL XPS 15 9575 9575-3795
| Reference / Part Number | 9575-3795 |
|---|---|
| Release date | May 2018, 8 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product colour | Black,Silver |
| Form factor | Convertible (Folder) |
| Colour name | Platinum Silver |
| Housing material | Aluminium,Carbon fibre |
| Market positioning | Business |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| HD type | Full HD |
| Touch technology | Multi-touch |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display surface | Matt |
| Display glass type | Gorilla Glass |
| Display bezel technology | InfinityEdge |
| Display brightness | 400 cd/m² |
| Pixel pitch | 0,179 x 0,179 mm |
| Dual-screen | No |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i5-8305G |
| Processor frequency | 2,8 GHz |
| Processor generation | 8th gen Intel® Core™ i5 |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor boost frequency | 3,8 GHz |
| System bus rate | 8 GT/s |
| Processor cache | 8 MB |
| Processor socket | BGA 2270 |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake |
| Bus type | DMI |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 8 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x8,2x4 |
| ECC supported by processor | No |
Memory
| Internal memory | 8 GB |
|---|---|
| Maximum internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
| Memory form factor | On-board |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Radeon RX Vega M GL |
| On-board graphics card model | Intel® HD Graphics 630 |
| Discrete GPU manufacturer | AMD |
| Discrete graphics memory type | HBM2 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card 4K support | Yes |
| On-board graphics card OpenGL version | 4.4 |
| Number of discrete graphics cards installed | 1 |
Audio
| Audio chip | Realtek ALC3271-CG |
|---|---|
| Audio system | MaxxAudio Pro |
| Number of built-in speakers | 2 |
| Speakers manufacturer | Waves |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,92 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera signal format | 720p |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Infrared (IR) camera | Yes |
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Antenna type | 2x2 |
| WLAN controller model | Killer Wireless-AC 1435 |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| DisplayPorts quantity | 0 |
| Thunderbolt 3 ports quantity | 2 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| PowerShare | Yes |
| Number of USB ports with PowerShare support | 2 |
| Number of Thunderbolt 3 ports with PowerShare support | 2 |
Performance
| Motherboard chipset | Intel GL82QM175 |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Full-size keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|---|
| Operating system architecture | 64-bit |
| Drivers included | Yes |
| Trial software | Microsoft Office (30 days Trial) |
| Bundled software | McAfee LiveSafe (12 Months Subscription) |
Processor special features
| Intel® My WiFi Technology (Intel® MWT) | Yes |
|---|---|
| Intel® Smart Response Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Processor package size | 31 x 58.8 mm |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 130408 |
Battery
| Battery capacity | 75 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Battery recharge time | 4 h |
| Battery charge indicator | Yes |
| Battery charge status button | Yes |
Power
| AC adapter power | 130 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 6,5 A |
| AC adapter output voltage | 20 V |
| DC-in jack | Yes |
| USB Power Delivery (USB PD) | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Noble |
| Fingerprint reader | Yes |
| Face recognition | Yes |
| Windows Hello | Yes |
| Password protection | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Sustainability
| Sustainability certificates | EPEAT Gold,ENERGY STAR |
|---|
Weight & dimensions
| Weight | 2 kg |
|---|---|
| Width | 354 mm |
| Depth | 235 mm |
| Height (front) | 9 mm |
| Height (rear) | 1,6 cm |
Packaging data
| Package material | Corrugated cardboard,Grey board,High-density polyethylene (HDPE),Low-density polyethylene (LDPE),Polypropylene (PP) |
|---|
Recycling data
| Grey board content per package | 414 g |
|---|---|
| Corrugated cardboard content per package | 486 g |
| Corrugated cardboard content per shipping (inner) case | 447 g |
| Corrugated cardboard content per sleeve for accessories | 39 g |
| High-density polyethylene (HDPE) content per package | 105 g |
| Low-density polyethylene (LDPE) content per package | 52 g |
| Polypropylene (PP) content per package | 13 g |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
| Quick start guide | Yes |
| Power cord included | Yes |
Logistics data
| Products per intermodal container (20ft) | 1300 pc(s) |
|---|---|
| Products per intermodal container (40ft, HC) | 3276 pc(s) |
| Pallet gross width | 100 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 114,2 cm |
| Pallet gross weight | 286,8 kg |
| Pallet volume weight | 228 kg |
| Master (outer) cases per pallet | 78 pc(s) |
| Master (outer) cases per pallet layer | 26 pc(s) |
| Layers per pallet | 3 pc(s) |
| Products per pallet layer | 26 pc(s) |
| Products per pallet | 78 pc(s) |
| Shipping (inner) case width | 9 cm |
| Shipping (inner) case length | 49,1 cm |
| Shipping (inner) case height | 33,4 cm |
| Shipping (inner) case gross weight | 3,57 kg |
| Shipping (inner) case volume weight | 2,46 kg |
| Maximum number of stacking cartons | 6 pc(s) |
Other features
| Machined aluminium design | Yes |
|---|---|
| USB Power Delivery revision | 2.0 |
| Maximum internal memory (64-bit) | 8 GB |
| Wide-angle lens front camera | Yes |
| EPEAT rating | 84,1 % |
| On/off button | Yes |
Frequently asked questions
Is the DELL XPS 15 9575 9575-3795 good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated AMD Radeon RX Vega M GL. Its card's page shows what level it handles current games at.
What is the screen of the DELL XPS 15 9575 9575-3795 like?
It carries a 15.6" 1920x1080 IPS 400 nits display.
Which processor and graphics card does the DELL XPS 15 9575 9575-3795 have?
It runs on the Intel Core i5 i5-8305G processor with the AMD Radeon RX Vega M GL graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the DELL XPS 15 9575 9575-3795 come with?
It comes with Windows 10 Home preinstalled.
Which ports does the DELL XPS 15 9575 9575-3795 have?
According to its spec sheet: 2 × Thunderbolt 3, 4 × USB-C, card reader, headphone jack (3.5 mm).
Does the DELL XPS 15 9575 9575-3795 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the DELL XPS 15 9575 9575-3795 have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the DELL XPS 15 9575 9575-3795 made of?
Its housing is made of Aluminium,Carbon fibre.
How much does the DELL XPS 15 9575 9575-3795 weigh?
It weighs 2 kg, a normal weight for its size: easy enough to move around.
When was the DELL XPS 15 9575 9575-3795 released?
Its release date is May 2018, 8 years ago.
