DELL XPS 15 9530 GCNWX
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 15.6" 1920x1200 WVA 60Hz 500 nits 100% sRGB |
| Hard drive | 1TB SSD M.2 |
| RAM | 16GB DDR5-SDRAM |
| Operating system | Windows 11 Pro |
| Graphics card | Intel Arc A370M 4GB GDDR6 |
Alternatives with equal or better features at a better price
From other brands
- 1
ASUS Vivobook 16 M1605NAQ 90NB1832-M00CX0
€5991062 - 2
ASUS Vivobook 16 M1605NAQ-MB029W 90NB1832-M00D20
€5991060 - 3
Lenovo IdeaPad Slim 3 16ARP10 83K800EMGE
€568.41059 - 4
Acer Aspire Lite AL16-54P-523X
€593.811057 - 5
Acer Aspire Go 15 AG15-42P-R8SZ
€529.991055 - 6
Lenovo IdeaPad Flex 5 14ABR8 82XX00JPGE
€588.911054 - 7
Lenovo IdeaPad Slim 3 16ARP10 83K800EUGE
€599.999.658 - 8
Lenovo IdeaPad Slim 3 15ARP10 83K7010CGE
€599.999.658 - 9
ASUS Vivobook 16 X1605VA-MB2146W
€5998.955
Full specifications of DELL XPS 15 9530 GCNWX
Reference / Part Number
GCNWX
Release date
July 2023, 3 years ago
Design
| Product type | Laptop |
|---|---|
| Product colour | Silver |
| Form factor | Clamshell |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | No |
| HD type | Full HD+ |
| Panel type | WVA |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display brightness | 500 cd/m² |
| Pixel density | 145 ppi |
| RGB colour space | sRGB |
| Colour gamut | 100 % |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 1650:1 |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-13700H |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor cores | 14 |
| Processor boost frequency | 5 GHz |
| Performance-core boost frequency | 5 GHz |
| Efficient-core boost frequency | 3,7 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Configurable TDP-down | 35 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | SO-DIMM |
| Memory slots | 2x SO-DIMM |
| Memory channels | Dual-channel |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD,SDHC,SDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | Intel Arc A370M |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
Audio
| Audio chip | Realtek ALC3281 |
|---|---|
| Number of built-in speakers | 4 |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,9 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6E (802.11ax) |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Ethernet LAN | No |
| Bluetooth | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Performance
| Ambient light sensor | Yes |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Pro |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| CPU configuration (max) | 1 |
|---|
Battery
| Battery capacity | 86 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Battery recharge time | 3 h |
| Fast charging | Yes |
| Battery charge indicator | Yes |
| Battery weight | 340 g |
Power
| USB Type-C charging port | Yes |
|---|---|
| USB Power Delivery (USB PD) | Yes |
| AC adapter power | 130 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB charging voltage | 20 V |
| USB charging current | 6.5 A |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Wedge |
| Fingerprint reader | Yes |
| Password protection | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 140 G |
| Non-operating shock | 160 G |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Weight & dimensions
| Weight | 1,92 kg |
|---|---|
| Width | 344,7 mm |
| Depth | 230,1 mm |
| Height (front) | 1,8 cm |
| Height (rear) | 1,17 cm |
Packaging content
| Cables included | AC |
|---|
Frequently asked questions
Is the DELL XPS 15 9530 GCNWX good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated Intel Arc A370M. Its card's page shows what level it handles current games at.
What is the screen of the DELL XPS 15 9530 GCNWX like?
It carries a 15.6" 1920x1200 WVA 60Hz 500 nits 100% sRGB display.
Which processor and graphics card does the DELL XPS 15 9530 GCNWX have?
It runs on the Intel Core i7-13700H processor with the Intel Arc A370M graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the DELL XPS 15 9530 GCNWX be upgraded?
Yes: it has 2 memory slots and takes up to 64 GB according to the manufacturer (it ships with 16GB).
Which operating system does the DELL XPS 15 9530 GCNWX come with?
It comes with Windows 11 Pro preinstalled.
Which ports does the DELL XPS 15 9530 GCNWX have?
According to its spec sheet: 2 × Thunderbolt 4, 1 × USB-C, card reader, headphone jack (3.5 mm).
Does the DELL XPS 15 9530 GCNWX have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the DELL XPS 15 9530 GCNWX have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the DELL XPS 15 9530 GCNWX weigh?
It weighs 1,92 kg, a normal weight for its size: easy enough to move around.
When was the DELL XPS 15 9530 GCNWX released?
Its release date is July 2023, 3 years ago.
