DELL XPS 13 9380 9380-5491
Specs
Prices
Main specs
| Processor | Intel Core i7-8565U 1,8GHz |
|---|---|
| Screen | 13.3" 3840x2160 400 nits |
| Hard drive | 256GB SSD M.2 |
| RAM | 8GB LPDDR3-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card | |
| Other | Keyboard German. |
Alternatives with equal or higher power at a similar or lower price
From DELL
From other brands
Full specifications of DELL XPS 13 9380 9380-5491
| Reference / Part Number | 9380-5491 |
|---|---|
| Also sold as | 9380-5484 |
| Release date | January 2019, 7 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | White |
| Form factor | Clamshell |
| Housing material | Aluminium,Carbon fibre |
Image gallery
Screen
| Display diagonal | 33,8 cm |
|---|---|
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | Yes |
| HD type | 4K Ultra HD |
| Touch technology | Multi-touch |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display bezel technology | InfinityEdge |
| Display brightness | 400 cd/m² |
| Dual-screen | No |
Processor
| Processor family | Intel® Core™ i7 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-8565U |
| Processor frequency | 1,8 GHz |
| Processor generation | 8th gen Intel® Core™ i7 |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor boost frequency | 4,6 GHz |
| System bus rate | 4 GT/s |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1528 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Whiskey Lake |
| Bus type | OPI |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-up frequency | 2 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-down | 10 W |
| Configurable TDP-down frequency | 0,8 GHz |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x4,2x2 |
| ECC supported by processor | No |
Memory
| Internal memory | 8 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | LPDDR3-SDRAM |
| Memory clock speed | 2133 MHz |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | NVMe,PCI Express |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3EA0 |
Audio
| Audio chip | Realtek ALC3271-CG |
|---|---|
| Audio system | MaxxAudio Pro |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,9 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera signal format | 720p |
| Front camera HD type | HD |
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Antenna type | 2x2 |
| WLAN controller model | Killer Wireless-AC 1435 |
| Ethernet LAN | No |
| Bluetooth | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| DisplayPorts quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Thunderbolt 3 ports quantity | 2 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTZ |
| Keyboard language | German |
| Keyboard backlit | Yes |
| Full-size keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|---|
| Operating system architecture | 64-bit |
| Operating system language | DEU,DUT,ENG,FRE,ITA |
| Trial software | McAfee®, Microsoft® Office |
| Bundled software | Financial Tracker & Retail Information |
Processor special features
| Intel® My WiFi Technology (Intel® MWT) | Yes |
|---|---|
| Intel® Smart Response Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Thunderbolt™ 3 Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 46x24 mm |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 149091 |
Battery
| Battery capacity | 52 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (max) | 11 h |
| Battery recharge time | 4 h |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 45 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
Security
| Cable lock slot | Yes |
|---|---|
| Fingerprint reader | Yes |
| Password protection | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 1,23 kg |
|---|---|
| Width | 301,8 mm |
| Depth | 199,2 mm |
| Height (front) | 7,8 mm |
| Height (rear) | 1,16 cm |
Packaging data
| Package width | 82,4 mm |
|---|---|
| Package depth | 450 mm |
| Package height | 292,5 mm |
| Package weight | 2,5 kg |
| Package material | Grey board,Corrugated cardboard,Low-density polyethylene (LDPE) |
Recycling data
| Paper molded pulp content per package | 0 g |
|---|---|
| Bamboo molded pulp content per package | 0 g |
| Wheat straw molded pulp content per package | 0 g |
| Grey board content per package | 331 g |
| Corrugated cardboard content per package | 432,8 g |
| Corrugated cardboard content per shipping (inner) case | 398,5 g |
| Corrugated cardboard content per box for accessories | 34,3 g |
| Corrugated cardboard content per sleeve for accessories | 0 g |
| Polyethylene terephthalate (PET) content per package | 0 g |
| High-density polyethylene (HDPE) content per package | 0 g |
| Low-density polyethylene (LDPE) content per package | 44,7 g |
| Polypropylene (PP) content per package | 0 g |
| Polystyrene (PS) content per package | 0 g |
| Other materials content per package | 0 g |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
| Quick start guide | Yes |
| Power cord included | Yes |
Logistics data
| Products per intermodal container (20ft) | 1800 pc(s) |
|---|---|
| Products per intermodal container (40ft) | 3780 pc(s) |
| Pallet gross width | 100 cm |
| Pallet gross length | 120 cm |
| Pallet gross weight | 232,7 kg |
| Pallet volume weight | 203,5 kg |
| Layers per pallet | 3 pc(s) |
| Products per pallet layer | 30 pc(s) |
| Products per pallet | 90 pc(s) |
Other features
| 3D | No |
|---|---|
| Maximum internal memory (64-bit) | 16 GB |
| EPEAT rating | 94,48 % |
| Package volume weight | 1,81 kg |
Frequently asked questions
Is the DELL XPS 13 9380 9380-5491 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics. Its card's page shows what level it handles current games at.
How long does the battery of the DELL XPS 13 9380 9380-5491 last?
The manufacturer declares up to 11 h of battery life. Real duration depends on brightness, workload and battery health.
What is the screen of the DELL XPS 13 9380 9380-5491 like?
It carries a 13.3" 3840x2160 400 nits display.
Which processor and graphics card does the DELL XPS 13 9380 9380-5491 have?
It runs on the Intel Core i7-8565U processor with the Intel UHD Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the DELL XPS 13 9380 9380-5491 be upgraded?
Yes: it has 2 memory slots and takes up to 16 GB according to the manufacturer (it ships with 8GB).
Which operating system does the DELL XPS 13 9380 9380-5491 come with?
It comes with Windows 10 Home preinstalled.
Which ports does the DELL XPS 13 9380 9380-5491 have?
According to its spec sheet: 2 × Thunderbolt 3, 1 × USB-C, card reader, headphone jack (3.5 mm).
Does the DELL XPS 13 9380 9380-5491 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the DELL XPS 13 9380 9380-5491 have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the DELL XPS 13 9380 9380-5491 made of?
Its housing is made of Aluminium,Carbon fibre.
How much does the DELL XPS 13 9380 9380-5491 weigh?
It weighs 1,23 kg: one of the light ones, easy to carry every day.
When was the DELL XPS 13 9380 9380-5491 released?
Its release date is January 2019, 7 years ago.
