ASUS Zenbook UX305CA-FB149T
Specs
Prices
Main specs
| Processor | Intel Core m3 m3-6Y30 0,9GHz |
|---|---|
| Screen | 13.3" 3200x1800 |
| Hard drive | 128GB SSD |
| RAM | 8GB LPDDR3-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card | Intel HD Graphics 515 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS Zenbook UX305CA-FB149T
| Reference / Part Number | 90NB0AA2-M03250 |
|---|---|
| Release date | November 2017, 8 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | White |
| Form factor | Clamshell |
Image gallery
Screen
| Display diagonal | 33,8 cm |
|---|---|
| Display resolution | 3200 x 1800 pixels |
| HD type | Quad HD+ |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
Processor
| Processor family | Intel® Core™ m3 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | m3-6Y30 |
| Processor frequency | 0,9 GHz |
| Processor generation | 6th gen Intel® Core™ m3 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 2,2 GHz |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Processor socket | BGA 1515 |
| Processor lithography | 14 nm |
| Processor operating modes | 32-bit,64-bit |
| Processor series | Intel Core m3-6Y series |
| Processor codename | Skylake |
| Bus type | OPI |
| Stepping | D1 |
| Thermal Design Power (TDP) | 4,5 W |
| Configurable TDP-up | 7 W |
| Configurable TDP-down | 3,8 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 10 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x2+2x1,2x2,1x4,4x1 |
| ECC supported by processor | No |
Memory
| Internal memory | 8 GB |
|---|---|
| Maximum internal memory | 8 GB |
| Internal memory type | LPDDR3-SDRAM |
| Memory clock speed | 1600 MHz |
Storage
| Total storage capacity | 128 GB |
|---|---|
| Storage media | SSD |
| Number of SSDs installed | 1 |
| SSD capacity | 128 GB |
| SSD interface | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | SD,SDHC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 515 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 850 MHz |
| Maximum on-board graphics card memory | 1,74 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x191E |
Audio
| Built-in microphone | Yes |
|---|
Camera
| Front camera | Yes |
|---|
Network
| Wi-Fi | Yes |
|---|---|
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 0 |
| DisplayPorts quantity | 0 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| Micro HDMI ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Full-size keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|
Processor special features
| Intel® Wireless Display (Intel® WiDi) | Yes |
|---|---|
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Smart Response Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel Clear Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel® Smart Cache | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 20 X 16.5 mm |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
| Processor code | SR2EN |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Graphics & IMC lithography | 14 nm |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Smart Response Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel TSX-NI version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 88198 |
| Conflict-Free processor | Yes |
Battery
| Battery capacity | 45 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
Power
| AC adapter power | 45 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| DC-in jack | Yes |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Certification | UL, TUV, CE Marking Compliance, FCC Compliance, CCC, EU Flower, Energy star, WEEE, RoHS |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 1,2 kg |
|---|---|
| Width | 324 mm |
| Depth | 226 mm |
| Height | 12,3 mm |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
Frequently asked questions
Is the ASUS Zenbook UX305CA-FB149T good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel HD Graphics 515. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Zenbook UX305CA-FB149T like?
It carries a 13.3" 3200x1800 display.
Which processor and graphics card does the ASUS Zenbook UX305CA-FB149T have?
It runs on the Intel Core m3 m3-6Y30 processor with the Intel HD Graphics 515 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS Zenbook UX305CA-FB149T come with?
It comes with Windows 10 Home preinstalled.
Which ports does the ASUS Zenbook UX305CA-FB149T have?
According to its spec sheet: 3 × USB-A, card reader, headphone jack (3.5 mm).
How much does the ASUS Zenbook UX305CA-FB149T weigh?
It weighs 1,2 kg: one of the light ones, easy to carry every day.
When was the ASUS Zenbook UX305CA-FB149T released?
Its release date is November 2017, 8 years ago.
