ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 14" 2880x1800 OLED 144Hz 500 nits 100% DCI-P3 |
| Hard drive | 2TB SSD M.2 |
| RAM | 32GB LPDDR5x-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | |
| Other | Keyboard Spanish. |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0
| Reference / Part Number | 90NB16V1-M00CC0 |
|---|---|
| Also sold as | 90NB16V1-M005V0, 90NB16V1-M00C90 |
| Release date | February 2026, 8 months ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product color | Gray |
| Form factor | Convertible (Detachable) |
| Color name | Moher Gray |
| Housing material | Magnesium,Aluminium |
| Market positioning | Home |
| Año de introducción | 2026 |
Image gallery
Screen
| Display diagonal | 14 " (35,6 cm) |
|---|---|
| Display resolution | 2880 x 1800 pixels |
| Touchscreen | Yes |
| HD type | 3K |
| Panel type | OLED |
| Display number of colors | 1.07 billion colors |
| Native aspect ratio | 16:10 |
| Display surface | Gloss |
| Display brightness | 500 cd/m² |
| Maximum display brightness (HDR) | 1000 cd/m² |
| RGB color space | DCI-P3 |
| Color gamut | 100 % |
| Low Blue Light technology | Yes |
| Maximum refresh rate | 144 Hz |
| Contrast ratio (typical) | 1000000:1 |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | DisplayHDR True Black 1000 |
Processor
| Processor family | Intel Core Ultra X9 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | 388H |
| Generación del procesador | Intel Core Ultra (Series 3) |
| Processor cores | 16 |
| Processor threads | 16 |
| Processor boost frequency | 5,1 GHz |
| Núcleos de rendimiento | 4 |
| Núcleos de eficiencia | 8 |
| Núcleos de eficiencia de baja potencia | 4 |
| Frecuencia turbo máxima del núcleo de rendimiento | 5.1 |
| Frecuencia turbo máxima del núcleo de eficiencia | 4 |
| Frecuencia turbo máxima del núcleo de eficiencia de baja potencia | 3.7 |
| Frecuencia base de núcleo de rendimiento | 2.1 |
| Frecuencia base de núcleo eficiente | 1.6 |
| Frecuencia base del núcleo de eficiencia de baja potencia | 1600 |
| Processor cache | 18 MB |
| Processor cache type | Smart Cache |
| Potencia base del procesador | 25 |
| Potencia turbo máxima | 80 |
Unidad de procesamiento neuronal (NPU)
| Copilot+ PC | Yes |
|---|---|
| Unidad de procesamiento neuronal (NPU) | Intel AI Boost |
| Soporte de dispersión | Yes |
| Soporte de efectos de Windows Studio | Yes |
| Soporte de tipos de datos de IA en el núcleo NPU | Int8 |
| Entornos de trabajo de software de IA compatibles con el núcleo NPU | ONNX RT,WebNN,Windows ML,OpenVINO |
| Rendimiento del núcleo NPU de hasta | 50 |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Memory form factor | On-board |
Storage
| Total storage capacity | 2 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 2 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Tamaño de la unidad SSD M.2 | 2280 (22 x 80 mm) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Arc B390 |
| Fabricante de GPU (unidad de procesamiento gráfico) integrada | Intel |
| On-board graphics card family | Intel Arc Graphics |
| On-board graphics card 4K support | Yes |
| Compatibilidad con 8K de adaptador de gráficos integrado | Yes |
| Graphics card Open GL support | Yes |
| Aceleración de trazado de rayos | Yes |
Audio
| Audio system | Smart Amp |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| HDMI version | 2.1 |
| Número de puertos Thunderbolt 4 | 2 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTY |
| Keyboard language | Spanish |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
| Trial software | 1-month trial for new Microsoft 365 customers. Credit card required. |
Battery
| Battery capacity | 99 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Control de energía
| Puerto de carga USB tipo C | Yes |
|---|---|
| AC adapter power | 100 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 5 A |
| AC adapter output voltage | 20 V |
| USB Power Delivery | Yes |
Security
| Windows Hello | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 3.6 lbs (1,65 kg) |
|---|---|
| Width | 12.2 " (310,1 mm) |
| Depth | 8.2 " (208,6 mm) |
| Height (front) | 0.8 " (1,96 cm) |
| Height (rear) | 0.9 " (2,34 cm) |
Packaging data
| Package width | 19.1 " (486 mm) |
|---|---|
| Package depth | 3.7 " (95 mm) |
| Package height | 10.9 " (277 mm) |
| Package weight | 11.8 lbs (5,34 kg) |
Packaging content
| AC adapter included | Yes |
|---|---|
| Bag included | Yes |
| Stylus pen | Yes |
Frequently asked questions
Is the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel Arc B390. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 like?
It carries a 14" 2880x1800 OLED 144Hz 500 nits 100% DCI-P3 display.
Which processor and graphics card does the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 have?
It runs on the Intel Core Ultra X9 388H processor with the Intel Arc B390 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 come with?
It comes with Windows 11 Home preinstalled.
Which ports does the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 have?
According to its spec sheet: 2 × Thunderbolt 4, 1 × USB-A, 1 × HDMI, headphone jack (3.5 mm).
Does the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 made of?
Its housing is made of Magnesium,Aluminium.
How much does the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 weigh?
It weighs 1,65 kg, a normal weight for its size: easy enough to move around.
When was the ASUS Zenbook Duo UX8407AA-SN066W 90NB16V1-M00CC0 released?
Its release date is February 2026, 8 months ago.
