ASUS X509UA-EJ07912
Specs
Prices
Main specs
| Processor | Intel Core i3-7020U 2,3GHz |
|---|---|
| Screen | 15.6" 1366x768 45% NTSC |
| Hard drive | 256GB SSD M.2 |
| RAM | 20GB DDR4-SDRAM |
| Operating system | No OS installed |
| Graphics card | Intel HD Graphics 620 |
Alternatives with equal or higher power at a similar or lower price
From ASUS
Full specifications of ASUS X509UA-EJ07912
| Reference / Part Number | X509UA-EJ07912 |
|---|---|
| Release date | January 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product color | Silver |
| Form factor | Clamshell |
| Color name | Transparent Silver |
| Market positioning | Home |
Image gallery
Screen
| Display diagonal | 15.6 " (39,6 cm) |
|---|---|
| Display resolution | 1366 x 768 pixels |
| Touchscreen | No |
| HD type | Full HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| RGB color space | NTSC |
| Color gamut | 45 % |
Processor
| Processor family | Intel® Core™ i3 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i3-7020U |
| Processor frequency | 2,3 GHz |
| Processor generation | Intel Core i3-7xxx |
| Processor cores | 2 |
| Processor cache | 3 MB |
| Bus type | OPI |
Memory
| Internal memory | 20 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Memory form factor | On-board + SO-DIMM |
| Memory slots | 1x SO-DIMM |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | NVMe,PCI Express 3.0 |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 620 |
Audio
| Audio system | SonicMaster |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | No |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Combo headphone/mic port | Yes |
| Charging port type | DC-in jack |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
Software
| Operating system installed | FreeDOS |
|---|
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
|---|---|
| Intel Clear Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Conflict-Free processor | Yes |
Battery
| Battery capacity | 32 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 2 |
Power
| AC adapter frequency | 50 - 60 Hz |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
Security
| Cable lock slot | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS,User |
Weight & dimensions
| Weight | 4.2 lbs (1,9 kg) |
|---|---|
| Width | 14.2 " (360 mm) |
| Depth | 9.3 " (235 mm) |
| Height | 0.9 " (22,9 mm) |
Frequently asked questions
Is the ASUS X509UA-EJ07912 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel HD Graphics 620. Its card's page shows what level it handles current games at.
What is the screen of the ASUS X509UA-EJ07912 like?
It carries a 15.6" 1366x768 45% NTSC display.
Which processor and graphics card does the ASUS X509UA-EJ07912 have?
It runs on the Intel Core i3-7020U processor with the Intel HD Graphics 620 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the ASUS X509UA-EJ07912 be upgraded?
Yes: it has 1 memory slot.
Which operating system does the ASUS X509UA-EJ07912 come with?
It comes with no operating system installed: the price does not include a license and you will have to install one yourself.
Which ports does the ASUS X509UA-EJ07912 have?
According to its spec sheet: 1 × USB-C, 1 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the ASUS X509UA-EJ07912 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the ASUS X509UA-EJ07912 weigh?
It weighs 1,9 kg, a normal weight for its size: easy enough to move around.
When was the ASUS X509UA-EJ07912 released?
Its release date is January 2022, 4 years ago.
