ASUS Vivobook S15 OLED S5504VN-L1060W
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 15.6" 1920x1080 OLED 120Hz 400 nits 100% DCI-P3 |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB LPDDR5-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | Intel Arc A350M 4GB GDDR6 |
Full specifications of ASUS Vivobook S15 OLED S5504VN-L1060W
| Reference / Part Number | 90NB0ZQ3-M007S0 |
|---|---|
| Release date | August 2023, 3 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Silver |
| Form factor | Clamshell |
| Colour name | Cool Silver |
| Housing material | Aluminium,Plastic |
| Market positioning | Home |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | OLED |
| Native aspect ratio | 16:9 |
| Display surface | Gloss |
| Display brightness | 400 cd/m² |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Maximum refresh rate | 120 Hz |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i5-13500H |
| Processor generation | 13th gen Intel® Core™ i5 |
| Processor cores | 12 |
| Processor threads | 16 |
| Processor boost frequency | 4,7 GHz |
| Performance cores | 4 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4,7 GHz |
| Efficient-core Max Turbo Frequency | 3,5 GHz |
| Processor cache | 18 MB |
| Processor cache type | Smart Cache |
| Configurable TDP-down | 35 W |
| Processor base power | 45 W |
| Maximum turbo power | 95 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory form factor | On-board |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | Intel Arc A350M |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Iris Xe Graphics |
Audio
| Audio system | Smart Amp |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | Full HD |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
| Trial software | 1-month trial for new Microsoft 365 customers, McAfee LiveSafe™ 30-day trial |
Processor special features
| Intel® Evo™ Platform Verified | Yes |
|---|---|
| CPU configuration (max) | 1 |
Battery
| Battery capacity | 70 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
Power
| AC adapter power | 90 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 4,74 A |
| AC adapter output voltage | 19 V |
| DC-in jack | Yes |
| USB Power Delivery (USB PD) | Yes |
Security
| Fingerprint reader | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS,User |
Weight & dimensions
| Weight | 1,7 kg |
|---|---|
| Width | 359,3 mm |
| Depth | 229,4 mm |
| Height | 17,9 mm |
Frequently asked questions
Is the ASUS Vivobook S15 OLED S5504VN-L1060W good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated Intel Arc A350M. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Vivobook S15 OLED S5504VN-L1060W like?
It carries a 15.6" 1920x1080 OLED 120Hz 400 nits 100% DCI-P3 display.
Which processor and graphics card does the ASUS Vivobook S15 OLED S5504VN-L1060W have?
It runs on the Intel Core i5-13500H processor with the Intel Arc A350M graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS Vivobook S15 OLED S5504VN-L1060W come with?
It comes with Windows 11 Home preinstalled.
Which ports does the ASUS Vivobook S15 OLED S5504VN-L1060W have?
According to its spec sheet: 1 × Thunderbolt 4, 1 × USB-A, 1 × HDMI, headphone jack (3.5 mm).
Does the ASUS Vivobook S15 OLED S5504VN-L1060W have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the ASUS Vivobook S15 OLED S5504VN-L1060W have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
What material is the ASUS Vivobook S15 OLED S5504VN-L1060W made of?
Its housing is made of Aluminium,Plastic.
How much does the ASUS Vivobook S15 OLED S5504VN-L1060W weigh?
It weighs 1,7 kg, a normal weight for its size: easy enough to move around.
When was the ASUS Vivobook S15 OLED S5504VN-L1060W released?
Its release date is August 2023, 3 years ago.
