ASUS Vivobook S14X OLED M5402RA-M9091
Specs
Prices
Main specs
| Processor | AMD Ryzen 7 6800H 3,2GHz |
|---|---|
| Screen | 14.5" 2880x1800 OLED 120Hz 100% DCI-P3 |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB DDR5-SDRAM |
| Operating system | No OS installed |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS Vivobook S14X OLED M5402RA-M9091
| Reference / Part Number | 90NB0XA1-M003M0 |
|---|---|
| Release date | March 2025, 1 year ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Black |
| Form factor | Clamshell |
| Colour name | Midnight Black |
| Housing material | Aluminium |
| Market positioning | Home |
| Introduction year | 2022 |
Image gallery
Screen
| Display diagonal | 36,8 cm |
|---|---|
| Display resolution | 2880 x 1800 pixels |
| Touchscreen | No |
| HD type | 2.8K |
| Panel type | OLED |
| Display number of colours | 1.07 billion colours |
| Native aspect ratio | 16:10 |
| Display surface | Gloss |
| Maximum display brightness (HDR) | 600 cd/m² |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Maximum refresh rate | 120 Hz |
| Contrast ratio (typical) | 1000000:1 |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | HDR True Black 600 |
Processor
| Processor family | AMD Ryzen™ 7 |
|---|---|
| Processor manufacturer | AMD |
| Processor model | 6800H |
| Processor frequency | 3,2 GHz |
| Processor generation | AMD Ryzen 6000 Series |
| Processor cores | 8 |
| Processor boost frequency | 4,7 GHz |
| Processor cache | 16 MB |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Memory form factor | On-board + SO-DIMM |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 1x SO-DIMM |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 3.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | AMD Radeon 680M |
| On-board GPU manufacturer | AMD |
Audio
| Audio system | Smart Amp |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1920 x 1080 pixels |
| Front camera HD type | Full HD |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | No |
|---|
Battery
| Battery capacity | 70 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 90 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 4,5 A |
| AC adapter output voltage | 20 V |
| USB Power Delivery (USB PD) | Yes |
Security
| Fingerprint reader | Yes |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Weight & dimensions
| Weight | 1,63 kg |
|---|---|
| Width | 322,3 mm |
| Depth | 230,9 mm |
| Height (front) | 1,79 cm |
| Height (rear) | 1,84 cm |
Packaging content
| AC adapter included | Yes |
|---|
Frequently asked questions
Is the ASUS Vivobook S14X OLED M5402RA-M9091 good for gaming?
This laptop was not built for gaming: it relies on the integrated AMD Radeon 680M. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Vivobook S14X OLED M5402RA-M9091 like?
It carries a 14.5" 2880x1800 OLED 120Hz 100% DCI-P3 display.
Which processor and graphics card does the ASUS Vivobook S14X OLED M5402RA-M9091 have?
It runs on the AMD Ryzen 7 6800H processor with the AMD Radeon 680M graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the ASUS Vivobook S14X OLED M5402RA-M9091 be upgraded?
It has 1 memory slot, but it already ships with the maximum it takes (16 GB).
Which operating system does the ASUS Vivobook S14X OLED M5402RA-M9091 come with?
It comes with no operating system installed: the price does not include a license and you will have to install one yourself.
Which ports does the ASUS Vivobook S14X OLED M5402RA-M9091 have?
According to its spec sheet: 2 × USB-C, 1 × USB-A, 1 × HDMI, headphone jack (3.5 mm).
Does the ASUS Vivobook S14X OLED M5402RA-M9091 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the ASUS Vivobook S14X OLED M5402RA-M9091 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
What material is the ASUS Vivobook S14X OLED M5402RA-M9091 made of?
Its housing is made of Aluminium.
How much does the ASUS Vivobook S14X OLED M5402RA-M9091 weigh?
It weighs 1,63 kg, a normal weight for its size: easy enough to move around.
When was the ASUS Vivobook S14X OLED M5402RA-M9091 released?
Its release date is March 2025, 1 year ago.
