ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660
Specs
Prices
Main specs
| Processor | Intel Celeron N4020 1,1GHz |
|---|---|
| Screen | 17.3" 1600x900 TN 200 nits 60% NTSC |
| Hard drive | 256GB SSD 2.5" |
| RAM | 4GB DDR4-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
Full specifications of ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660
| Reference / Part Number | 90NB0IF2-M03660 |
|---|---|
| Release date | April 2020, 6 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Grey |
| Form factor | Clamshell |
| Colour name | Star Grey |
| Housing material | Plastic |
Image gallery
Screen
| Display diagonal | 43,9 cm |
|---|---|
| Display resolution | 1600 x 900 pixels |
| Touchscreen | No |
| HD type | HD+ |
| Panel type | TN |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display surface | Matt |
| Anti-glare screen | Yes |
| Display brightness | 200 cd/m² |
| RGB colour space | NTSC |
| Colour gamut | 60 % |
Processor
| Processor family | Intel® Celeron® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | N4020 |
| Processor frequency | 1,1 GHz |
| Processor boost frequency | 2,8 GHz |
| Processor cache | 4 MB |
Memory
| Internal memory | 4 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Memory form factor | SO-DIMM |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | SATA |
| SSD form factor | 2.5" |
| Card reader integrated | Yes |
| Compatible memory cards | SD,MMC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics 600 |
| On-board GPU manufacturer | Intel |
Audio
| Audio system | SonicMaster |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Infrared (IR) camera | No |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Antenna type | 1x1 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 1.4 |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTY |
| Keyboard backlit | No |
Software
| Operating system installed | Windows 10 Home |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 42 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
Power
| AC adapter power | 33 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 1,75 A |
| AC adapter output voltage | 19 V |
| DC-in jack | Yes |
Security
| Cable lock slot | No |
|---|---|
| Fingerprint reader | No |
| Trusted Platform Module (TPM) | No |
| Password protection | Yes |
| Password protection type | BIOS,User |
Weight & dimensions
| Weight | 2,1 kg |
|---|---|
| Width | 411 mm |
| Depth | 270 mm |
| Height (front) | 2,2 cm |
| Height (rear) | 2,3 cm |
Frequently asked questions
Is the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics 600. Its card's page shows what level it handles current games at.
What is the screen of the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 like?
It carries a 17.3" 1600x900 TN 200 nits 60% NTSC display.
Which processor and graphics card does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 have?
It runs on the Intel Celeron N4020 processor with the Intel UHD Graphics 600 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 be upgraded?
Yes: it has 2 memory slots.
Which operating system does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 come with?
It comes with Windows 10 Home preinstalled.
Which ports does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 have?
According to its spec sheet: 1 × USB-C, 1 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 have a backlit keyboard?
No, according to its spec sheet the keyboard is not backlit.
Does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
What material is the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 made of?
Its housing is made of Plastic.
How much does the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 weigh?
It weighs 2,1 kg, a normal weight for its size: easy enough to move around.
When was the ASUS Vivobook 17 A705MA(GML-R)-BX188T 90NB0IF2-M03660 released?
Its release date is April 2020, 6 years ago.
