ASUS R705MA-BX080T
Specs
Prices
Main specs
| Processor | Intel Pentium Silver N5000 1,1GHz |
|---|---|
| Screen | 17.3" 1366x768 |
| Hard drive | 256GB SSD |
| RAM | 8GB DDR4-SDRAM |
| Operating system | Windows 10 Home |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS R705MA-BX080T
| Reference / Part Number | 90NB0IF2-M01710 |
|---|---|
| Release date | July 2019, 7 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Grey |
| Form factor | Clamshell |
Image gallery
Screen
| Display diagonal | 43,9 cm |
|---|---|
| Display resolution | 1366 x 768 pixels |
| Touchscreen | No |
| HD type | HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display surface | Matt |
| Dual-screen | No |
Processor
| Processor family | Intel® Pentium® Silver |
|---|---|
| Processor manufacturer | Intel |
| Processor model | N5000 |
| Processor frequency | 1,1 GHz |
| Processor boost frequency | 2,7 GHz |
| Processor threads | 4 |
| Processor cores | 4 |
| Processor cache | 4 MB |
| Processor cache type | L3 |
| Processor socket | BGA 1090 |
| Processor lithography | 14 nm |
| Processor operating modes | 32-bit,64-bit |
| Processor codename | Gemini Lake |
| Stepping | B0 |
| Thermal Design Power (TDP) | 6 W |
| Scenario Design Power (SDP) | 4,8 W |
| Tjunction | 105 °C |
| Maximum number of PCI Express lanes | 6 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x4+1x2,2x1+1x2+1x2,4x1 |
Memory
| Internal memory | 8 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
Storage
| Total storage capacity | 256 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| Card reader integrated | Yes |
| Compatible memory cards | SDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics 605 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card burst frequency | 750 MHz |
| On-board graphics card dynamic frequency (max) | 750 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of execution units | 18 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card ID | 0x3184 |
Audio
| Audio system | SonicMaster |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|
Processor special features
| Intel® Anti-Theft Technology (Intel® AT) | No |
|---|---|
| Intel® Smart Response Technology | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 25 x 24 mm |
| Processor code | SR3RZ |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| UART | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 128990 |
| Conflict-Free processor | Yes |
Battery
| Battery capacity | 42 Wh |
|---|---|
| Number of battery cells | 3 |
Power
| AC adapter power | 33 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter output current | 1,74 A |
| AC adapter output voltage | 19 V |
Weight & dimensions
| Weight | 2,1 kg |
|---|---|
| Width | 411 mm |
| Depth | 270 mm |
| Height | 22,6 mm |
Frequently asked questions
Is the ASUS R705MA-BX080T good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics 605. Its card's page shows what level it handles current games at.
What is the screen of the ASUS R705MA-BX080T like?
It carries a 17.3" 1366x768 display.
Which processor and graphics card does the ASUS R705MA-BX080T have?
It runs on the Intel Pentium Silver N5000 processor with the Intel UHD Graphics 605 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS R705MA-BX080T come with?
It comes with Windows 10 Home preinstalled.
Which ports does the ASUS R705MA-BX080T have?
According to its spec sheet: 1 × USB-C, 1 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the ASUS R705MA-BX080T have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the ASUS R705MA-BX080T weigh?
It weighs 2,1 kg, a normal weight for its size: easy enough to move around.
When was the ASUS R705MA-BX080T released?
Its release date is July 2019, 7 years ago.
