ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690
Specs
Prices
Main specs
| Processor | Intel Core i7-10510U 1,8GHz |
|---|---|
| Screen | 14" 1920x1080 IPS 60Hz 45% NTSC |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB DDR4-SDRAM |
| Operating system | Windows 10 Pro |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From ASUS
Full specifications of ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690
| Reference / Part Number | 90NX02N1-M18690 |
|---|---|
| Release date | December 2020, 5 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Black |
| Form factor | Clamshell |
| Colour name | Star Black |
| Market positioning | Business |
| Rugged design | Yes |
Image gallery
Screen
| Display diagonal | 35,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| RGB colour space | NTSC |
| Colour gamut | 45 % |
| Maximum refresh rate | 60 Hz |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i7-10510U |
| Processor frequency | 1,8 GHz |
| Processor generation | 10th gen Intel® Core™ i5 |
| Processor cores | 4 |
| Processor boost frequency | 4,9 GHz |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| Configurable TDP-up frequency | 2,3 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-down | 10 W |
| Configurable TDP-down frequency | 0,8 GHz |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Memory form factor | SO-DIMM |
| Memory slots | 2x SO-DIMM |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | NVMe,PCI Express 3.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card 4K support | Yes |
Audio
| Audio system | SonicMaster |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of microphones | 1 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Performance
| Repairability index | 6.7 |
|---|
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard backlit colour | White |
| Island-style keyboard | Yes |
| Spill-resistant keyboard | Yes |
Software
| Operating system installed | Windows 10 Pro |
|---|---|
| Operating system architecture | 64-bit |
| Pre-installed software | MyASUS |
| Trial software | McAfee |
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
|---|---|
| Intel Clear Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 48 Wh |
|---|---|
| Number of battery cells | 3 |
| Removable battery | No |
Power
| USB Power Delivery (USB PD) | Yes |
|---|---|
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| DC-in jack | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Fingerprint reader | Yes |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS,HDD |
Certificates
| Compliance certificates | CE |
|---|---|
| Certification | FCC Compliance, BSMI, CCC, CB, EPEAT |
| MIL-STD-810G compliant | Yes |
Sustainability
| Sustainability certificates | ENERGY STAR,UL ECOLOGO |
|---|
Weight & dimensions
| Weight | 1,5 kg |
|---|---|
| Width | 325,3 mm |
| Depth | 232,9 mm |
| Height | 19,9 mm |
Frequently asked questions
Is the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics. Its card's page shows what level it handles current games at.
What is the screen of the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 like?
It carries a 14" 1920x1080 IPS 60Hz 45% NTSC display.
Which processor and graphics card does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 have?
It runs on the Intel Core i7-10510U processor with the Intel UHD Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 be upgraded?
Yes: it has 2 memory slots and takes up to 32 GB according to the manufacturer (it ships with 16GB).
Which operating system does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 come with?
It comes with Windows 10 Pro preinstalled.
Which ports does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 have?
According to its spec sheet: 1 × USB-C, 2 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 weigh?
It weighs 1,5 kg: one of the light ones, easy to carry every day.
When was the ASUS ExpertBook P2451FA-EB0620R 90NX02N1-M18690 released?
Its release date is December 2020, 5 years ago.
