ASUS E406MA-DB21
Specs
Prices
Main specs
| Processor | Intel Pentium Silver N5000 1,1GHz |
|---|---|
| Screen | 14" 1920x1080 |
| Hard drive | 64GB eMMC |
| RAM | 4GB LPDDR4-SDRAM |
| Operating system | Windows 10 |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From ASUS
From other brands
Full specifications of ASUS E406MA-DB21
| Reference / Part Number | E406MA-DB21 |
|---|---|
| Release date | May 2018, 8 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Grey |
| Form factor | Clamshell |
| Colour name | Star Grey |
Image gallery
Screen
| Display diagonal | 35,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display surface | Matt |
Processor
| Processor family | Intel® Pentium® Silver |
|---|---|
| Processor manufacturer | Intel |
| Processor model | N5000 |
| Processor frequency | 1,1 GHz |
| Processor boost frequency | 2,7 GHz |
| Processor threads | 4 |
| Processor cores | 4 |
| Processor cache | 4 MB |
| Processor cache type | L3 |
| Processor socket | BGA 1090 |
| Processor lithography | 14 nm |
| Processor operating modes | 32-bit,64-bit |
| Processor codename | Gemini Lake |
| Stepping | B0 |
| Thermal Design Power (TDP) | 6 W |
| Scenario Design Power (SDP) | 4,8 W |
| Tjunction | 105 °C |
| Maximum number of PCI Express lanes | 6 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x4+1x2,2x1+1x2+1x2,4x1 |
| ECC supported by processor | No |
Memory
| Internal memory | 4 GB |
|---|---|
| Maximum internal memory | 4 GB |
| Internal memory type | LPDDR4-SDRAM |
| Memory form factor | On-board |
Storage
| Total storage capacity | 64 GB |
|---|---|
| Storage media | eMMC |
| Optical drive type | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics 605 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card burst frequency | 750 MHz |
| On-board graphics card dynamic frequency (max) | 750 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of execution units | 18 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card ID | 0x3184 |
Audio
| Audio system | SonicMaster |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | No |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Mini DisplayPort/Thunderbolt combo port | No |
| Combo headphone/mic port | Yes |
| ExpressCard slot | No |
| SmartCard slot | No |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Full-size keyboard | Yes |
| Windows keys | Yes |
Software
| Operating system installed | Windows 10 |
|---|---|
| Operating system architecture | 64-bit |
Processor special features
| Intel® Anti-Theft Technology (Intel® AT) | No |
|---|---|
| Intel® Smart Response Technology | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor package size | 25 x 24 mm |
| Processor code | SR3RZ |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| UART | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 128990 |
| Conflict-Free processor | Yes |
Battery
| Battery capacity | 56 Wh |
|---|---|
| Number of battery cells | 3 |
Power
| AC adapter power | 33 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 1,75 A |
| AC adapter output voltage | 19 V |
Certificates
| Certification | UL, TÜV, BSMI, Australia C-TICK / NZ A-Tick Compliance, CCC, CB, Erp 2013 |
|---|
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Weight | 1,3 kg |
|---|---|
| Width | 326,4 mm |
| Depth | 226,5 mm |
| Height (front) | 1,58 cm |
| Height (rear) | 1,76 cm |
Other features
| Maximum internal memory (64-bit) | 4 GB |
|---|
Frequently asked questions
Is the ASUS E406MA-DB21 good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics 605. Its card's page shows what level it handles current games at.
What is the screen of the ASUS E406MA-DB21 like?
It carries a 14" 1920x1080 display.
Which processor and graphics card does the ASUS E406MA-DB21 have?
It runs on the Intel Pentium Silver N5000 processor with the Intel UHD Graphics 605 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS E406MA-DB21 come with?
It comes with Windows 10 preinstalled.
Which ports does the ASUS E406MA-DB21 have?
According to its spec sheet: 2 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the ASUS E406MA-DB21 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the ASUS E406MA-DB21 weigh?
It weighs 1,3 kg: one of the light ones, easy to carry every day.
When was the ASUS E406MA-DB21 released?
Its release date is May 2018, 8 years ago.
