ASUS BR1102FGA-MK0156XA
Specs
Prices
Main specs
| Processor | Intel N100 0,8GHz |
|---|---|
| Screen | 11.6" 1366x768 IPS 250 nits 50% NTSC |
| Hard drive | 128GB SSD M.2 |
| RAM | 8GB DDR4-SDRAM |
| Operating system | Windows 11 Pro Education |
| Graphics card |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of ASUS BR1102FGA-MK0156XA
| Reference / Part Number | 90NX0601-M005L0 |
|---|---|
| Release date | March 2023, 3 years ago |
Design
| Product type | Hybrid (2-in-1) |
|---|---|
| Product colour | Grey |
| Form factor | Convertible (Folder) |
| Colour name | Mineral Grey |
| Housing material | Plastic |
| Market positioning | Educational |
Image gallery
Screen
| Display diagonal | 29,5 cm |
|---|---|
| Display resolution | 1366 x 768 pixels |
| Touchscreen | Yes |
| HD type | HD |
| Panel type | IPS |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Display surface | Gloss |
| Display brightness | 250 cd/m² |
| RGB colour space | NTSC |
| Colour gamut | 50 % |
Processor
| Processor family | Intel® N |
|---|---|
| Processor manufacturer | Intel |
| Processor model | N100 |
| Processor frequency | 0,8 GHz |
| Processor cores | 4 |
| Processor boost frequency | 3,4 GHz |
| Processor cache | 6 MB |
Memory
| Internal memory | 8 GB |
|---|---|
| Maximum internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory form factor | On-board |
Storage
| Total storage capacity | 128 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 128 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 128 GB |
| SSD interface | PCI Express 3.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics |
| On-board GPU manufacturer | Intel |
Audio
| Built-in microphone | Yes |
|---|
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | HD |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 2.0 Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 1.4 |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard layout | QWERTY |
Software
| Operating system installed | Windows 11 Pro Education |
|---|---|
| Operating system architecture | 64-bit |
Battery
| Battery capacity | 50 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
Power
| USB Type-C charging port | Yes |
|---|---|
| AC adapter power | 45 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 2,25 A |
| AC adapter output voltage | 20 V |
| USB Power Delivery (USB PD) | Yes |
Security
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS,User |
Certificates
| Compliance certificates | RoHS,REACH |
|---|
Sustainability
| Sustainability certificates | EPEAT Gold,ENERGY STAR,Forest Stewardship Council (FSC) Recycled,TCO |
|---|
Weight & dimensions
| Weight | 1,47 kg |
|---|---|
| Width | 296,9 mm |
| Depth | 208,5 mm |
| Height (front) | 2,11 cm |
| Height (rear) | 2,12 cm |
Frequently asked questions
Is the ASUS BR1102FGA-MK0156XA good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel UHD Graphics. Its card's page shows what level it handles current games at.
What is the screen of the ASUS BR1102FGA-MK0156XA like?
It carries a 11.6" 1366x768 IPS 250 nits 50% NTSC display.
Which processor and graphics card does the ASUS BR1102FGA-MK0156XA have?
It runs on the Intel N100 processor with the Intel UHD Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the ASUS BR1102FGA-MK0156XA come with?
It comes with Windows 11 Pro Education preinstalled.
Which ports does the ASUS BR1102FGA-MK0156XA have?
According to its spec sheet: 2 × USB-C, 1 × USB-A, 1 × HDMI, Ethernet (RJ-45), headphone jack (3.5 mm).
Does the ASUS BR1102FGA-MK0156XA have a touch screen?
Yes, according to its spec sheet the screen is a touch screen.
What material is the ASUS BR1102FGA-MK0156XA made of?
Its housing is made of Plastic.
How much does the ASUS BR1102FGA-MK0156XA weigh?
It weighs 1,47 kg: one of the light ones, easy to carry every day.
When was the ASUS BR1102FGA-MK0156XA released?
Its release date is March 2023, 3 years ago.
