Alienware x16 R2 NAX106E-EHLS
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 16" 2560x1600 WVA 240Hz 300 nits 100% DCI-P3 |
| Hard drive | 2TB SSD M.2 |
| RAM | 32GB LPDDR5x-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | NVIDIA GeForce RTX 4080 12GB GDDR6 |
Alternatives with equal or higher power at a similar or lower price
From other brands
Full specifications of Alienware x16 R2 NAX106E-EHLS
| Reference / Part Number | NAX106E-EHLS |
|---|---|
| Also sold as | NAX106-EHLS, NAX106-EHLSC, NAX106E-EHLSC |
| Release date | October 2024, 2 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Silver |
| Form factor | Clamshell |
| Colour name | Lunar Silver |
| Market positioning | Gaming |
Image gallery
Screen
| Display diagonal | 40,6 cm |
|---|---|
| Display resolution | 2560 x 1600 pixels |
| Touchscreen | No |
| HD type | Quad HD+ |
| Panel type | WVA |
| LED backlight | Yes |
| Native aspect ratio | 16:10 |
| Anti-glare screen | Yes |
| Display brightness | 300 cd/m² |
| Pixel density | 188,7 ppi |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Maximum refresh rate | 240 Hz |
| Contrast ratio (typical) | 1000:1 |
Processor
| Processor family | Intel Core Ultra 9 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | 185H |
| Processor generation | Intel Core Ultra (Series 1) |
| Processor threads | 22 |
| Processor boost frequency | 5,1 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 5,1 GHz |
| Efficient-core Max Turbo Frequency | 3,8 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2,5 GHz |
| Performance-core base frequency | 2,3 GHz |
| Efficient-core base frequency | 1,8 GHz |
| Low Power Efficient-core Base Frequency | 1000 MHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Processor base power | 45 W |
| Maximum turbo power | 115 W |
Neural processor unit (NPU)
| Neural processor unit (NPU) | Intel AI Boost |
|---|---|
| Maximum frequency NPU | 1,4 GHz |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML,ONNX RT,OpenVINO,Windows ML |
Memory
| Internal memory | 32 GB |
|---|---|
| Maximum internal memory | 32 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Memory clock speed | 7467 MHz |
| Memory form factor | On-board |
| Memory channels | Dual-channel |
Storage
| Total storage capacity | 2 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 2 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 4080 |
| On-board graphics card model | Intel Arc Graphics |
| Discrete graphics card memory | 12 GB |
| Discrete graphics memory type | GDDR6 |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel Arc Graphics |
Audio
| Audio chip | Realtek ALC3281 |
|---|---|
| Number of built-in speakers | 6 |
| Built-in microphone | Yes |
| Number of microphones | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 2,07 MP |
| Front camera resolution | 1920 x 1080 pixels |
| Front camera HD type | Full HD |
| Video capturing speed | 30 fps |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be) |
| Antenna type | 2x2 |
| WLAN controller model | Killer Wi-Fi 7 BE1750 |
| WLAN controller manufacturer | Killer |
| Bluetooth | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 0 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Mini DisplayPorts quantity | 1 |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| PowerShare | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard backlit colour | RGB |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
Battery
| Battery capacity | 90 Wh |
|---|---|
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Fast charging | Yes |
| Battery weight | 330 g |
Power
| AC adapter frequency | 50 - 60 Hz |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| DC-in jack | Yes |
| USB Power Delivery (USB PD) | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Weight & dimensions
| Width | 364,8 mm |
|---|---|
| Depth | 290 mm |
| Height (front) | 1,86 cm |
| Height (rear) | 1,86 cm |
Frequently asked questions
Is the Alienware x16 R2 NAX106E-EHLS good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated NVIDIA GeForce RTX 4080. Its card's page shows what level it handles current games at.
What is the screen of the Alienware x16 R2 NAX106E-EHLS like?
It carries a 16" 2560x1600 WVA 240Hz 300 nits 100% DCI-P3 display.
Which processor and graphics card does the Alienware x16 R2 NAX106E-EHLS have?
It runs on the Intel Core Ultra 9 185H processor with the NVIDIA GeForce RTX 4080 graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Alienware x16 R2 NAX106E-EHLS come with?
It comes with Windows 11 Home preinstalled.
Which ports does the Alienware x16 R2 NAX106E-EHLS have?
According to its spec sheet: 1 × Thunderbolt 4, 1 × USB-C, 2 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the Alienware x16 R2 NAX106E-EHLS have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Alienware x16 R2 NAX106E-EHLS have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
When was the Alienware x16 R2 NAX106E-EHLS released?
Its release date is October 2024, 2 years ago.
