Alienware x14 R1 AWR1-1986
Specs
Prices
Main specs
| Processor | |
|---|---|
| Screen | 14" 1920x1080 WVA 144Hz 400 nits 100% DCI-P3 |
| Hard drive | 512GB SSD M.2 |
| RAM | 16GB LPDDR5-SDRAM |
| Operating system | Windows 11 Home |
| Graphics card | Intel Arc A370M 4GB GDDR6 |
| Other | Keyboard German. |
Alternatives with equal or higher power at a similar or lower price
From other brands
- 1
ASUS Vivobook 18 M1807HA#B0DS5N6MWW
€8491059 - 2
Lenovo IdeaPad Slim 5 16IMH10 83V70077GE
€864.381055 - 3
Lenovo IdeaPad Slim 3 15AHP10 83KA000QUS
€823.531055 - 4
Lenovo IdeaPad 5 2-in-1 14IRH9 83KX000SGE
€804.231053 - 5
Lenovo IdeaPad 5 2-in-1 14AHP11 83UJ001GGE
€879.999.955 - 6
Acer Aspire 17 A17-51M-920Y
€8999.953 - 7
DELL Pro 14 14255 5G8FC
€808.229.852 - 8
DELL Pro 14 Essential PV14255 RV811
€869.639.453
Full specifications of Alienware x14 R1 AWR1-1986
| Reference / Part Number | AWR1-1986 |
|---|---|
| Release date | April 2022, 4 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Black,Silver |
| Form factor | Clamshell |
| Colour name | Lunar Light |
| Market positioning | Gaming |
Image gallery
Screen
| Display diagonal | 35,6 cm |
|---|---|
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | WVA |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| Display brightness | 400 cd/m² |
| Pixel pitch | 0,172 x 0,172 mm |
| Pixel density | 157 ppi |
| RGB colour space | DCI-P3 |
| Colour gamut | 100 % |
| Display response rise/fall | 7 ms |
| Maximum refresh rate | 144 Hz |
| Contrast ratio (typical) | 1000:1 |
Processor
| Processor family | Intel® Core™ i5 |
|---|---|
| Processor manufacturer | Intel |
| Processor model | i5-12500H |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor cores | 12 |
| Processor cache | 18 MB |
| Configurable TDP-down | 35 W |
Memory
| Internal memory | 16 GB |
|---|---|
| Maximum internal memory | 16 GB |
| Internal memory type | LPDDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory form factor | On-board |
Storage
| Total storage capacity | 512 GB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | NVMe,PCI Express |
| NVMe | Yes |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | Intel Arc A370M |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete GPU manufacturer | Intel |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR6 |
| NVIDIA G-SYNC | Yes |
Audio
| Audio chip | Realtek ALC3281-CG |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution (numeric) | 0,92 MP |
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Infrared (IR) camera | Yes |
Network
| Mobile network connection | No |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax) |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Combo headphone/mic port | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
Keyboard
| Numeric keypad | No |
|---|---|
| Pointing device | Touchpad |
| Keyboard language | German |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Home |
|---|---|
| Operating system architecture | 64-bit |
| Trial software | Microsoft® Office 30 Day Trial - Excludes Office License |
Processor special features
| Intel Flex Memory Access | Yes |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Battery
| Battery capacity | 80,5 Wh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 6 |
| Battery voltage | 11,4 V |
| Battery recharge time | 3 h |
| Fast charging | Yes |
| Battery weight | 320 g |
Power
| USB Type-C charging port | Yes |
|---|---|
| USB Power Delivery (USB PD) | Yes |
| AC adapter power | 130 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 6,5 A |
| USB charging voltage | 5,20 V |
| USB charging current | 6.5 A |
Security
| Password protection | Yes |
|---|---|
| Password protection type | BIOS,HDD,Supervisor,User |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | -15,2 - 3048 m |
| Non-operating altitude | -15,2 - 10668 m |
| Operating shock | 140 G |
| Non-operating shock | 160 G |
| Operating vibration | 0,66 G |
| Non-operating vibration | 1,3 G |
Weight & dimensions
| Weight | 1,84 kg |
|---|---|
| Width | 321,5 mm |
| Depth | 262,8 mm |
| Height | 14,5 mm |
Packaging data
| Package width | 330 mm |
|---|---|
| Package depth | 397 mm |
| Package height | 112 mm |
| Package weight | 4,13 kg |
| Package material | Grey board,Corrugated cardboard,Polyethylene terephthalate (PET),High-density polyethylene (HDPE),Polypropylene (PP) |
Recycling data
| Paper molded pulp content per package | 0 g |
|---|---|
| Bamboo molded pulp content per package | 0 g |
| Wheat straw molded pulp content per package | 0 g |
| Grey board content per package | 774 g |
| Corrugated cardboard content per package | 978 g |
| Corrugated cardboard content per shipping (inner) case | 452 g |
| Corrugated cardboard content per box for accessories | 518 g |
| Corrugated cardboard content per sleeve for accessories | 8 g |
| Polyethylene terephthalate (PET) content per package | 4 g |
| High-density polyethylene (HDPE) content per package | 125 g |
| Low-density polyethylene (LDPE) content per package | 0 g |
| Polypropylene (PP) content per package | 19 g |
| Polystyrene (PS) content per package | 0 g |
| Other materials content per package | 0 g |
Packaging content
| Cables included | AC |
|---|
Logistics data
| Products per intermodal container (20ft) | 1360 pc(s) |
|---|---|
| Products per intermodal container (40ft, HC) | 3024 pc(s) |
| Pallet gross width | 100 cm |
| Pallet gross length | 120 cm |
| Pallet gross weight | 305,4 kg |
| Pallet volume weight | 229,6 kg |
| Layers per pallet | 9 pc(s) |
| Products per pallet layer | 8 pc(s) |
| Products per pallet | 72 pc(s) |
| Maximum number of stacking cartons | 18 pc(s) |
Other features
| EPEAT rating | 92,21 % |
|---|
Frequently asked questions
Is the Alienware x14 R1 AWR1-1986 good for gaming?
You can game on it, though this laptop was not built for it: it carries the dedicated Intel Arc A370M. Its card's page shows what level it handles current games at.
What is the screen of the Alienware x14 R1 AWR1-1986 like?
It carries a 14" 1920x1080 WVA 144Hz 400 nits 100% DCI-P3 display.
Which processor and graphics card does the Alienware x14 R1 AWR1-1986 have?
It runs on the Intel Core i5-12500H processor with the Intel Arc A370M graphics. Their pages carry their benchmarks, ranking position and alternatives.
Which operating system does the Alienware x14 R1 AWR1-1986 come with?
It comes with Windows 11 Home preinstalled.
Which ports does the Alienware x14 R1 AWR1-1986 have?
According to its spec sheet: 1 × Thunderbolt 4, 1 × USB-C, 1 × USB-A, 1 × HDMI, card reader, headphone jack (3.5 mm).
Does the Alienware x14 R1 AWR1-1986 have a backlit keyboard?
Yes, according to its spec sheet the keyboard is backlit.
Does the Alienware x14 R1 AWR1-1986 have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the Alienware x14 R1 AWR1-1986 weigh?
It weighs 1,84 kg, a normal weight for its size: easy enough to move around.
When was the Alienware x14 R1 AWR1-1986 released?
Its release date is April 2022, 4 years ago.
