Acer Aspire E E5-511-C8EK
Specs
Prices
Main specs
| Processor | Intel Celeron N2940 1,83GHz |
|---|---|
| Screen | 15.6" 1366x768 |
| Hard drive | 500GB HDD |
| RAM | 4GB DDR3L-SDRAM |
| Operating system | No OS installed |
| Graphics card | Intel HD Graphics |
Alternatives with equal or higher power at a similar or lower price
From Acer
Full specifications of Acer Aspire E E5-511-C8EK
| Reference / Part Number | NX.MPLEX.040 |
|---|---|
| Release date | January 2017, 9 years ago |
Design
| Product type | Laptop |
|---|---|
| Product colour | Red |
| Form factor | Clamshell |
Image gallery
Screen
| Display diagonal | 39,6 cm |
|---|---|
| Display resolution | 1366 x 768 pixels |
| Touchscreen | No |
| HD type | HD |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
Processor
| Processor family | Intel® Celeron® |
|---|---|
| Processor manufacturer | Intel |
| Processor model | N2940 |
| Processor frequency | 1,83 GHz |
| Processor boost frequency | 2,25 GHz |
| Processor threads | 4 |
| Processor cores | 4 |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor socket | BGA 1170 |
| Processor lithography | 22 nm |
| Processor operating modes | 32-bit,64-bit |
| Processor series | Intel Celeron Processor N2000 series for Mobile |
| Processor codename | Bay Trail |
| Stepping | C0 |
| Thermal Design Power (TDP) | 7,5 W |
| Scenario Design Power (SDP) | 4,5 W |
| Tjunction | 100 °C |
| Maximum number of PCI Express lanes | 4 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x4 |
| ECC supported by processor | No |
Memory
| Internal memory | 4 GB |
|---|---|
| Maximum internal memory | 8 GB |
| Internal memory type | DDR3L-SDRAM |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 1x SO-DIMM |
Storage
| Total storage capacity | 500 GB |
|---|---|
| Storage media | HDD |
| Optical drive type | No |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Graphics
| On-board graphics card | Yes |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 313 MHz |
| On-board graphics card burst frequency | 854 MHz |
| On-board graphics card dynamic frequency (max) | 854 MHz |
Audio
| Number of built-in speakers | 2 |
|---|---|
| Built-in microphone | Yes |
Camera
| Front camera | Yes |
|---|
Network
| Wi-Fi | Yes |
|---|---|
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| VGA (D-Sub) ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Docking connector | No |
| Charging port type | DC-in jack |
| Total number of SATA connectors | 2 |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Pointing device | Touchpad |
| Windows keys | Yes |
Software
| Operating system installed | Linux Linpus |
|---|
Processor special features
| Intel® Wireless Display (Intel® WiDi) | Yes |
|---|---|
| Intel Smart Connect Technology | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel Enhanced Halt State | Yes |
| Intel® Secure Key | Yes |
| Intel 64 | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Processor package size | 25 x 27 mm |
| Processor code | SR1YV |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Graphics & IMC lithography | 22 nm |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel Smart Connect Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 82104 |
| Conflict-Free processor | Yes |
Battery
| Battery technology | Lithium-Ion (Li-Ion) |
|---|---|
| Number of battery cells | 6 |
| Battery capacity | 4700 mAh |
| Standby time | 2500 day(s) |
Power
| AC adapter power | 40 W |
|---|---|
| AC adapter frequency | 50 - 60 Hz |
Weight & dimensions
| Weight | 2,5 kg |
|---|---|
| Width | 381 mm |
| Depth | 256 mm |
| Height | 30,3 mm |
| Height (front) | 2,53 cm |
| Height (rear) | 3,03 cm |
Packaging content
| Manual | Yes |
|---|---|
| Power cord included | Yes |
Other features
| AC adapter included | Yes |
|---|---|
| 3D | No |
Frequently asked questions
Is the Acer Aspire E E5-511-C8EK good for gaming?
This laptop was not built for gaming: it relies on the integrated Intel HD Graphics. Its card's page shows what level it handles current games at.
What is the screen of the Acer Aspire E E5-511-C8EK like?
It carries a 15.6" 1366x768 display.
Which processor and graphics card does the Acer Aspire E E5-511-C8EK have?
It runs on the Intel Celeron N2940 processor with the Intel HD Graphics graphics. Their pages carry their benchmarks, ranking position and alternatives.
Can the RAM of the Acer Aspire E E5-511-C8EK be upgraded?
Yes: it has 1 memory slot and takes up to 8 GB according to the manufacturer (it ships with 4GB).
Which operating system does the Acer Aspire E E5-511-C8EK come with?
It comes with no operating system installed: the price does not include a license and you will have to install one yourself.
Which ports does the Acer Aspire E E5-511-C8EK have?
According to its spec sheet: 1 × USB-A, 1 × HDMI, Ethernet (RJ-45), card reader, headphone jack (3.5 mm).
Does the Acer Aspire E E5-511-C8EK have a touch screen?
No, according to its spec sheet the screen is not a touch screen.
How much does the Acer Aspire E E5-511-C8EK weigh?
It weighs 2,5 kg: one of the heavy ones, more of a desk machine than a daily commuter.
When was the Acer Aspire E E5-511-C8EK released?
Its release date is January 2017, 9 years ago.
